Panduit
Dura-Ty™ DTKH-0 Dura-Ty Cable Tie Kit, Black, Acetal, UV, 600"L, 200lb, PK1
MFG #DTKH-0
$93.67 / E
(Must order in increments of 10/E)
(Must order in increments of 10/E)
Product Description:
Panduit DTKH-0 Dura-Ty™ Cable Tie Kit is weather, chemical, and UV-resistant for harsh outdoor power and communications applications. The durable locking mechanism, complete with double stainless steel locking barbs, provides a consistent, reliable connection and high-impact resistance and strength. Heavy cross section, are made of Weather Resistant Acetal. They are black in color and come in a package with 1 reel of 50' (15,240mm) strapping and 25 heads.
HESCO Part Number
PANDTKH0
UPC
074983010691
Manufacturer Part Number
DTKH-0
Manufacturer
Panduit
Panduit
Dura-Ty™ DTKH-0 Dura-Ty Cable Tie Kit, Black, Acetal, UV, 600"L, 200lb, PK1
MFG #DTKH-0
Product Description:
Panduit DTKH-0 Dura-Ty™ Cable Tie Kit is weather, chemical, and UV-resistant for harsh outdoor power and communications applications. The durable locking mechanism, complete with double stainless steel locking barbs, provides a consistent, reliable connection and high-impact resistance and strength. Heavy cross section, are made of Weather Resistant Acetal. They are black in color and come in a package with 1 reel of 50' (15,240mm) strapping and 25 heads.
HESCO Part Number
PANDTKH0
UPC
074983010691
Manufacturer Part Number
DTKH-0
Manufacturer
Panduit
$93.67 / E
(Must order in increments of 10/E)
(Must order in increments of 10/E)
- Features
- Specifications
- Resources
- Standards Met: UL 62275 (File #E56854), Type 2, 2S, CE TR-TSY-000789, RoHS Compliant
- No
Specifications
| Country of Origin | : | China |
| Any Reason Not to Sell | : | N |
| Product Segment | : | IEI |
| Body Thickness (In.) | : | 0.064 |
| Body Thickness (mm) | : | 1.6 |
| Minimum Operating Temperature (°C) | : | -60 |
| Minimum Installation Temperature (°F) | : | -4 |
| For Use With | : | GTH-E, GS4EH-E, STH2, STHV |
| Overall Length (In.) | : | 600 |
| Body Width (In.) | : | 0.33 |
| Material | : | Acetal |
| Environment | : | Indoor/Outdoor |
| Maximum Bundle Diameter (In.) | : | 0.18 |
| Resistance Properties | : | UV-Resistant |
| Minimum Installation Temperature (°C) | : | -20 |
| Minimum Loop Tensile Strength (N) | : | 890 |
| Minimum Bundle Diameter (In.) | : | 0.02 |
| Overall Length (mm) | : | 15240 |
| Minimum Bundle Diameter (mm) | : | 0.5 |
| Maximum Operating Temperature (°F) | : | 185 |
| Maximum Bundle Diameter (mm) | : | 4.8 |
| Maximum Operating Temperature (°C) | : | 85 |
| Color | : | Black |
| Body Width (mm) | : | 8.4 |
| Sub Brand | : | Dura-Ty™ |
| Minimum Operating Temperature (°F) | : | -76 |
| Product Type | : | Cable Tie |
| Minimum Loop Tensile Strength (lb) | : | 200 |
Packaging Details | ||
| UPC | : | 07498301069 |
| GTIN Package | : | 00074983010691 |
| Standard Package Volume Ft3 | : | 0.0901 |
| Standard Package Weight Pounds | : | 1.0000 |
| Std Package Height In | : | .7 |
| Std Package Height MM | : | 17.78 |
| Std Package Length In | : | 21.5 |
| Std Package Length MM | : | 546.1 |
| Std Package Width In | : | 10 |
| Std Package Width MM | : | 254 |
| Std. Pkg. UOM | : | Kit |
| UOM EA PK | : | EA |
| Std. Pkg. Qty. | : | 1 |
| GTIN Carton | : | 50074983010696 |
| Standard Carton Volume Ft3 | : | 1.8029 |
| Standard Carton Weight Pounds | : | 20.0000 |
| Std Carton Height In | : | 12.91 |
| Std Carton Height MM | : | 327.914 |
| Std Carton Length In | : | 22.96 |
| Std Carton Length MM | : | 583.184 |
| Std Carton Width In | : | 10.46 |
| Std Carton Width MM | : | 265.684 |
| Std Ctn Qty | : | 20 |
| Min. Order UOM | : | Kit |
| EAN | : | 00074983010691 |
| REACH Status | : | N |
| California Pro65 Cancer | : | No |
| ARRA Compliant | : | N |
| Mercury Content Indicator | : | N |
| Lead Content Indicator | : | N |
| Restricted Use of Hazardous Substances | : | N |
| Hazardous Material Flag | : | N |
| Min Order Qty | : | 10.0000 |
| Pallet Quantity | : | 480 |
| Pallet Volume | : | 43.268750 |
| Pallet Weight | : | 480.0000 |
| RoHS Compliant | : | Compliant |
