CCH25-S10-M Cable Clamp
MFG #CCH25-S10-M
Product Description:
Fixed diameter cable clamp, heavy duty, #10 screw (M5), .25" (6.4mm) bundle, white, bulk package.
HESCO Part Number
PANCCH25S10M
UPC
074983600526
Manufacturer Part Number
CCH25-S10-M
Manufacturer
Panduit
CCH25-S10-M Cable Clamp
MFG #CCH25-S10-M
Product Description:
Fixed diameter cable clamp, heavy duty, #10 screw (M5), .25" (6.4mm) bundle, white, bulk package.
HESCO Part Number
PANCCH25S10M
UPC
074983600526
Manufacturer Part Number
CCH25-S10-M
Manufacturer
Panduit
- Features
- Specifications
- Resources
- Product
- No
- Standards Met: UL Recognized E136577, RoHS Compliant
Specifications
| Country of Origin | : | United States |
| Any Reason Not to Sell | : | N |
| Product Segment | : | IEI |
| Overall Width (mm) | : | 12.7 |
| Maximum Operating Temperature (°C) | : | 85 |
| Maximum Bundle Diameter (mm) | : | 6.4 |
| Mounting Hole Diameter (mm) | : | 5.1 |
| Note | : | Not available in Japan |
| Overall Height (In.) | : | 0.35 |
| Mounting Hole Diameter (In.) | : | 0.203 |
| Material | : | Nylon 6.6 |
| Maximum Flange Thickness (mm) | : | 1.3 |
| Overall Length (mm) | : | 16.2 |
| Minimum Operating Temperature (°C) | : | -60 |
| Minimum Operating Temperature (°F) | : | -76 |
| Environment | : | Indoor |
| Overall Width (In.) | : | 0.5 |
| Maximum Operating Temperature (°F) | : | 185 |
| Overall Height (mm) | : | 8.9 |
| Color | : | Natural |
| Maximum Bundle Diameter (In.) | : | 0.25 |
| Overall Length (In.) | : | 0.635 |
| Mount Method | : | Screw-On |
| Product Type | : | Cable Clamp |
| Application | : | For securing wires and cables via fixed diameter clamping |
| Maximum Flange Thickness (In.) | : | 1/8 |
| Compatible Screw Size | : | #10 |
Packaging Details | ||
| UPC | : | 07498360052 |
| GTIN Package | : | 00074983600526 |
| Standard Package Volume Ft3 | : | 0.1410 |
| Standard Package Weight Pounds | : | 1.8000 |
| Std Package Height In | : | 2.95 |
| Std Package Height MM | : | 74.93 |
| Std Package Length In | : | 11.45 |
| Std Package Length MM | : | 290.83 |
| Std Package Width In | : | 9.95 |
| Std Package Width MM | : | 252.73 |
| Std. Pkg. UOM | : | Piece |
| UOM EA PK | : | PK |
| Std. Pkg. Qty. | : | 1000 |
| GTIN Carton | : | 50074983600521 |
| Standard Carton Volume Ft3 | : | 0.7051 |
| Standard Carton Weight Pounds | : | 9.0000 |
| Std Carton Height In | : | 9.8 |
| Std Carton Height MM | : | 248.92 |
| Std Carton Length In | : | 14.55 |
| Std Carton Length MM | : | 369.57 |
| Std Carton Width In | : | 9.3 |
| Std Carton Width MM | : | 236.22 |
| Std Ctn Qty | : | 5000 |
| Min. Order UOM | : | Piece |
| EAN | : | 00074983600526 |
| REACH Status | : | N |
| California Pro65 Cancer | : | No |
| ARRA Compliant | : | Y |
| Mercury Content Indicator | : | N |
| Hazardous Material Flag | : | N |
| Min Order Qty | : | 5,000.0000 |
| Pallet Quantity | : | 300,000 |
| Pallet Volume | : | 42.304688 |
| Pallet Weight | : | 540.0000 |
| RoHS Compliant | : | Compliant |
