Low Peak Fuse
MFG #LP-CC-2-1/2
$60.13Â /Â E
EACH
EACH
HESCO Part Number
BUSLPCC21/2
UPC
051712180542
Manufacturer Part Number
LP-CC-2-1/2
Manufacturer
Bussmann
Low Peak Fuse
MFG #LP-CC-2-1/2
HESCO Part Number
BUSLPCC21/2
UPC
051712180542
Manufacturer Part Number
LP-CC-2-1/2
Manufacturer
Bussmann
$60.13Â /Â E
EACH
EACH
- Specifications
- Resources
Specifications
| Height | :Â Â | 1.5 IN |
| Length | :Â Â | .41 IN |
| Width | :Â Â | .41 IN |
| Weight | :Â Â | .15 LB |
| Type | :Â Â | Current-limiting, Time-delay |
| Special Features | :Â Â | Rejection Style |
| Application | :Â Â | Specialized circuits and industrial control |
| Voltage Rating | :Â Â | 600 Vac, 300 Vdc |
| Amperage Rating | :Â Â | 2-1/2A |
| Interrupt Rating | :Â Â | 200 kAIC at 600 Vac, 20 kAIC at 300 Vdc |
| Class | :Â Â | Class CC |
| Connection | :Â Â | Ferrule end X ferrule end |
| Material Type | :Â Â | Melamine tube |
| Packaging Type | :Â Â | Standard |
| Diameter | :Â Â | .40625 IN |
| Quantity | :Â Â | Carton: 10 |
| Fuse Indicator | :Â Â | Non Indicating |
| Response Time | :Â Â | 12s at 200% |
| Number Of Elements | :Â Â | Dual |
Specifications
Height :Â Â 1.5 IN Length :Â Â .41 IN Width :Â Â .41 IN Weight :Â Â .15 LB Type :Â Â Current-limiting, Time-delay Special Features :Â Â Rejection Style Application :Â Â Specialized circuits and industrial control Voltage Rating :Â Â 600 Vac, 300 Vdc Amperage Rating :Â Â 2-1/2A Interrupt Rating :Â Â 200 kAIC at 600 Vac, 20 kAIC at 300 Vdc Class :Â Â Class CC Connection :Â Â Ferrule end X ferrule end Material Type :Â Â Melamine tube Packaging Type :Â Â Standard Diameter :Â Â .40625 IN Quantity :Â Â Carton: 10 Fuse Indicator :Â Â Non Indicating Response Time :Â Â 12s at 200% Number Of Elements :Â Â Dual - Downloads
bus-ele-cat-1007-flc-2017-complete.pdfBus_Ele_DS_1023_LP-CC.pdf
