Time-Delay, Low-Breaking Capacity Fuse
MFG #S506-315-R
$5.16Â /Â E
(Must order in increments of 5/E)
(Must order in increments of 5/E)
HESCO Part Number
BUSS506315R
UPC
051712650236
Manufacturer Part Number
S506-315-R
Manufacturer
Bussmann
Time-Delay, Low-Breaking Capacity Fuse
MFG #S506-315-R
HESCO Part Number
BUSS506315R
UPC
051712650236
Manufacturer Part Number
S506-315-R
Manufacturer
Bussmann
$5.16Â /Â E
(Must order in increments of 5/E)
(Must order in increments of 5/E)
- Features
- Specifications
- CCC Marked
- RoHS Compliant
- VDE
Specifications
| Type | :Â Â | Small dimension, European (IEC) |
| Application | :Â Â | Electronic circuits |
| Amperage Rating | :Â Â | 315A |
| Voltage Rating | :Â Â | 250 Vac or less, 32 Vdc (self certified) |
| Interrupt Rating | :Â Â | 35A at 250 Vac |
| Fuse Indicator | :Â Â | Non Indicating |
| Packaging Type | :Â Â | Standard |
| Voltage Drop | :Â Â | Maximum: 68.5 mV |
| Material | :Â Â | Glass tube, nickel-plated brass endcaps |
| Frequency Rating | :Â Â | 50 Hz |
| Connection | :Â Â | Ferrule end X ferrule end |
| Height | :Â Â | .787 IN |
| Length | :Â Â | .787 IN |
| Width | :Â Â | .197 IN |
| Weight | :Â Â | .005 LB |
- CCC Marked
- RoHS Compliant
- VDE
Specifications
Type :Â Â Small dimension, European (IEC) Application :Â Â Electronic circuits Amperage Rating :Â Â 315A Voltage Rating :Â Â 250 Vac or less, 32 Vdc (self certified) Interrupt Rating :Â Â 35A at 250 Vac Fuse Indicator :Â Â Non Indicating Packaging Type :Â Â Standard Voltage Drop :Â Â Maximum: 68.5 mV Material :Â Â Glass tube, nickel-plated brass endcaps Frequency Rating :Â Â 50 Hz Connection :Â Â Ferrule end X ferrule end Height :Â Â .787 IN Length :Â Â .787 IN Width :Â Â .197 IN Weight :Â Â .005 LB
