Hoffman
Panel-Mount Fan Speed Controls, 120V 50/60Hz, Gray, Polycarbonate
MFG #AFANTSC
$740.00Â /Â E
EACH
EACH
Product Description:
Panel-Mount Fan Speed Controls control fan speed, optimizing airflow in a rack or cabinet. This Panel-Mount Fan Speed Controls, AFANTSC item is rated 120V 50/60Hz with a material of Polycarbonate colored Gray.
HESCO Part Number
HFAFANTSC
UPC
783510138578
Manufacturer Part Number
AFANTSC
Manufacturer
Hoffman
Hoffman
Panel-Mount Fan Speed Controls, 120V 50/60Hz, Gray, Polycarbonate
MFG #AFANTSC
Product Description:
Panel-Mount Fan Speed Controls control fan speed, optimizing airflow in a rack or cabinet. This Panel-Mount Fan Speed Controls, AFANTSC item is rated 120V 50/60Hz with a material of Polycarbonate colored Gray.
HESCO Part Number
HFAFANTSC
UPC
783510138578
Manufacturer Part Number
AFANTSC
Manufacturer
Hoffman
$740.00Â /Â E
EACH
EACH
- Features
- Specifications
- Resources
- Automatically adjusts fan speed depending on remote temperature sensor input
- Temperature set point is field adjustable; preset at 35 C (95 F)
- Idle speed and temperature slope are field-adjustable
- Push-to-reset thermal circuit breaker inside control housing
- Compact polycarbonate control housing can be mounted in any position
- NEMA 5-15R outlet provides power to fan
- Six-foot (1.83-m) power cord plugs into standard 120 V, 50 or 60 Hz outlet
- Remote temperature sensor with 10-ft. (3.05-m) lead mounts in airflow
- Mounting brackets included
Specifications
| Width (W) | :Â Â | 80 |
| Material | :Â Â | Polycarbonate |
| Finish | :Â Â | Smooth Gloss |
| Color | :Â Â | Gray |
| Thickness (T) | :Â Â | 2.5 |
| Height (H) | :Â Â | 55 |
| Input Voltage AC | :Â Â | 100 |
| Depth (D) | :Â Â | 120 |
| Weight | :Â Â | 1.2 |
| Size | :Â Â | 2.16 x 3.15 x 4.72 in |
| Voltage Rating | :Â Â | 100 - 120 VAC |
| Frequency Rating | :Â Â | 50/60Hz |
| Housing Material | :Â Â | Polycarbonate |
Certificate
Certificate - CE-UKCA-00094_Accy-Enclosure - NAM-US
Certificate - CERT-00272 - NAM-US
Certificate - CE-UKCA-00003_Accy-Enclosure - NAM-US
Instruction Manual
Instruction Manual - 87782308 - NAM-US
Downloads
Spec Sheet
Data Sheet
Data Sheet - Spec-00583 - NAM-CA
Data Sheet - Spec-00816 - NAM-US
Data Sheet - Spec-01352 - NAM-CA
Certificate - CE-UKCA-00094_Accy-Enclosure - NAM-USCertificate - CERT-00272 - NAM-USCertificate - CE-UKCA-00003_Accy-Enclosure - NAM-USInstruction Manual
Instruction Manual - 87782308 - NAM-USDownloads
Spec SheetData Sheet
Data Sheet - Spec-00583 - NAM-CAData Sheet - Spec-00816 - NAM-USData Sheet - Spec-01352 - NAM-CA- Automatically adjusts fan speed depending on remote temperature sensor input
- Temperature set point is field adjustable; preset at 35 C (95 F)
- Idle speed and temperature slope are field-adjustable
- Push-to-reset thermal circuit breaker inside control housing
- Compact polycarbonate control housing can be mounted in any position
- NEMA 5-15R outlet provides power to fan
- Six-foot (1.83-m) power cord plugs into standard 120 V, 50 or 60 Hz outlet
- Remote temperature sensor with 10-ft. (3.05-m) lead mounts in airflow
- Mounting brackets included
Specifications
Width (W) :Â Â 80 Material :Â Â Polycarbonate Finish :Â Â Smooth Gloss Color :Â Â Gray Thickness (T) :Â Â 2.5 Height (H) :Â Â 55 Input Voltage AC :Â Â 100 Depth (D) :Â Â 120 Weight :Â Â 1.2 Size :Â Â 2.16 x 3.15 x 4.72 in Voltage Rating :Â Â 100 - 120 VAC Frequency Rating :Â Â 50/60Hz Housing Material :Â Â Polycarbonate - CertificateCertificate - CE-UKCA-00094_Accy-Enclosure - NAM-USCertificate - CERT-00272 - NAM-USCertificate - CE-UKCA-00003_Accy-Enclosure - NAM-US
Instruction ManualInstruction Manual - 87782308 - NAM-US
DownloadsSpec Sheet
Data SheetData Sheet - Spec-00583 - NAM-CAData Sheet - Spec-00816 - NAM-USData Sheet - Spec-01352 - NAM-CA
