Hoffman
Wiring Trough NEMA Type 12 and 3R, 6.00x6.00x48.00, Gray, Fiberglass
MFG #F6648FG
$1,098.00Â /Â E
EACH
EACH
Product Description:
Fiberglass Wiring Trough meets Type 12, 3R ratings for corrosive indoor or outdoor applications. This Wiring Trough NEMA Type 12 and 3R, F6648FG item measures 6.00x6.00x48.00 inches with a material of Fiberglass colored Gray.
HESCO Part Number
HFF6648FG
UPC
783510159801
Manufacturer Part Number
F6648FG
Manufacturer
Hoffman
Hoffman
Wiring Trough NEMA Type 12 and 3R, 6.00x6.00x48.00, Gray, Fiberglass
MFG #F6648FG
Product Description:
Fiberglass Wiring Trough meets Type 12, 3R ratings for corrosive indoor or outdoor applications. This Wiring Trough NEMA Type 12 and 3R, F6648FG item measures 6.00x6.00x48.00 inches with a material of Fiberglass colored Gray.
HESCO Part Number
HFF6648FG
UPC
783510159801
Manufacturer Part Number
F6648FG
Manufacturer
Hoffman
$1,098.00Â /Â E
EACH
EACH
- Features
- Specifications
- Resources
- Captivated Monel cover screws
- Seams are sealed
- Oil-resistant gasket attached with oil-resistant adhesive
- No holes or knockouts
- Pultruded fiberglass polyester bodies and covers
Specifications
| Type | :Â Â | Trough |
| Height (H) | :Â Â | 152 |
| Width (W) | :Â Â | 152 |
| Depth (D) | :Â Â | 1,219 |
| Protection Rating | :Â Â | NEMA Type 12 |
| Finish | :Â Â | Smooth Matte |
| Color | :Â Â | Gray |
| Color Code | :Â Â | ANSI 61 |
| Thickness (T) | :Â Â | 3.2 |
| Opening Quantity | :Â Â | 4 |
| Cover Screw Quantity | :Â Â | 12 |
| Modification Services | :Â Â | Yes |
| IP Rating | :Â Â | IP55 |
| Wireway | :Â Â | Wiring Troughs |
| NEMA Rating | :Â Â | 12 Indoor, dust-resistant |
| Weight | :Â Â | 14 |
| Height | :Â Â | 6 in |
| Material | :Â Â | Fiberglass |
Data Sheet
Data Sheet - Spec-00332 - NAM-CA
Certificate
Certificate - CE-UKCA-00022_WW-Non-Metallic - NAM-US
Downloads
Spec Sheet
Instruction Manual
Instruction Manual - 23353001 - NAM-US
Data Sheet - Spec-00332 - NAM-CACertificate
Certificate - CE-UKCA-00022_WW-Non-Metallic - NAM-USDownloads
Spec SheetInstruction Manual
Instruction Manual - 23353001 - NAM-US- Captivated Monel cover screws
- Seams are sealed
- Oil-resistant gasket attached with oil-resistant adhesive
- No holes or knockouts
- Pultruded fiberglass polyester bodies and covers
Specifications
Type :Â Â Trough Height (H) :Â Â 152 Width (W) :Â Â 152 Depth (D) :Â Â 1,219 Protection Rating :Â Â NEMA Type 12 Finish :Â Â Smooth Matte Color :Â Â Gray Color Code :Â Â ANSI 61 Thickness (T) :Â Â 3.2 Opening Quantity :Â Â 4 Cover Screw Quantity :Â Â 12 Modification Services :Â Â Yes IP Rating :Â Â IP55 Wireway :Â Â Wiring Troughs NEMA Rating :Â Â 12 Indoor, dust-resistant Weight :Â Â 14 Height :Â Â 6 in Material :Â Â Fiberglass - Data SheetData Sheet - Spec-00332 - NAM-CA
CertificateCertificate - CE-UKCA-00022_WW-Non-Metallic - NAM-US
DownloadsSpec Sheet
Instruction ManualInstruction Manual - 23353001 - NAM-US
