ProLine Network Switch Cabinet no Sides, 2000x1000x1200mm, Lt Gray, Steel
MFG #PNS201012BNS
$6,982.00Â /Â E
EACH
EACH
Product Description:
ProLine Network Switch Cabinets are thermal cable management solution for large data network switches. This ProLine Network Switch Cabinet no Sides, PNS201012BNS item measures 2000x1000x1200mm with a material of Steel colored Lt Gray.
HESCO Part Number
HFPNS201012BNS
UPC
783510239954
Manufacturer Part Number
PNS201012BNS
Manufacturer
Hoffman
ProLine Network Switch Cabinet no Sides, 2000x1000x1200mm, Lt Gray, Steel
MFG #PNS201012BNS
Product Description:
ProLine Network Switch Cabinets are thermal cable management solution for large data network switches. This ProLine Network Switch Cabinet no Sides, PNS201012BNS item measures 2000x1000x1200mm with a material of Steel colored Lt Gray.
HESCO Part Number
HFPNS201012BNS
UPC
783510239954
Manufacturer Part Number
PNS201012BNS
Manufacturer
Hoffman
$6,982.00Â /Â E
EACH
EACH
- Features
- Specifications
- Resources
- Meets all CISCO 6509, 6513, 7009 and 7018 Series network switch installation and operational requirements
- Integrated right-to-left airflow ducting ensures core switch is supplied with air from cold aisle
- Front door has keyed multi-point vault-style latch system and central key lock to ensure security
- Split overlapping rear doors provide quick access to equipment without blocking aisles (7009 and 7018 Series have split front and rear doors)
- Front vertical cable manager has integral hinged doors to house, protect and provide aesthetic appearance
- Front cable manager uses arrowhead support fingers to support and ensure proper bend radius, provide increased cable capacity and facilitate assembly
- Available standard with sides or without for use in ganged applications
- Top-mount sliding gland plate provides large opening for cables, pre-terminated cable bundles and patch panels
- Open base allows under floor cable entry
- 6509 and 6513 Series only:
- Network core switch shelf located at bottom of cabinet (2 RU on 65089/6513 Series; 0 RU on 7018 Series)
- Attractive, rigid front door made of aluminum extrusions and formed perforated steel, with more than 70 percent open space for free flow of cool air to equipment
- Rear upper-mounted 4 RU equipment mounting angles provide for PDUs, fiber-to-copper transition, splitter equipment and other 19-in. rack-mounted equipment
- Rear horizontal and vertical cable management provide support and transition of permanent link cables
- Switch shelf is included with cabinet
- Front set of 19-inch mounting rails are tapped (10-32) per EIA standards
- Top and sides are formed steel
- Sides secured with fasteners
Specifications
| Height (H) | :Â Â | 1,991 |
| Width (W) | :Â Â | 999 |
| Depth (D) | :Â Â | 1,199 |
| Product Family | :Â Â | ProLine |
| Color Code | :Â Â | RAL 9005 |
| Thickness (T) | :Â Â | 1.52 |
| Modification Services | :Â Â | Yes |
| Weight | :Â Â | 483 |
| Sub Brand | :Â Â | ProLine |
| Material | :Â Â | Steel |
| Finish | :Â Â | Lt Gray |
| Color | :Â Â | Lt Gray |
