Straight Blade Devices, Weather Resistant Receptacles, Duplex, Commercial/Industrial Grade, 2-Pole 3-Wire Grounding, 15A 125V, 5-15R, Ivory
MFG #5362IWR
$13.85 / E
EACH
EACH
Product Description:
Straight Blade Devices, Weather Resistant Receptacles, Duplex, Commercial/Industrial Grade, 2-Pole 3-Wire Grounding, 15A 125V, 5-15R, Ivory
HESCO Part Number
HUB5362IWR
UPC
783585358659
Manufacturer Part Number
5362IWR
Manufacturer
Hubbell Wiring Device
Straight Blade Devices, Weather Resistant Receptacles, Duplex, Commercial/Industrial Grade, 2-Pole 3-Wire Grounding, 15A 125V, 5-15R, Ivory
MFG #5362IWR
Product Description:
Straight Blade Devices, Weather Resistant Receptacles, Duplex, Commercial/Industrial Grade, 2-Pole 3-Wire Grounding, 15A 125V, 5-15R, Ivory
HESCO Part Number
HUB5362IWR
UPC
783585358659
Manufacturer Part Number
5362IWR
Manufacturer
Hubbell Wiring Device
$13.85 / E
EACH
EACH
- Features
- Specifications
- Resources
- Weather-resistance complies with national electrical code requirements
- Finder Groove Face
- Triple wipe contacts
- Compact design
- Self Grounding
Specifications
| Buy American Compliant | : | Yes |
| Country of Origin | : | US |
| Dimensions | : | 3.28 in x 1.41 in x 1.09 in |
| Each - Width | : | 1.900 in |
| Height | : | 1.09 in |
| Industry Standard(s) | : | UL File No. E2186, Certified to CSA 22.2, No. 42 File 285, Fed. Spec. W-C-596, NEMA® WD-6 Compliant |
| Length | : | 3.28 in |
| Amperage Rating | : | 20 A |
| Application | : | Hubbell-Pro Extra Heavy Duty |
| Color | : | Ivory |
| Dielectric Strength | : | Withstands 2,000V minimum |
| Mounting | : | Screw Mount |
| NEMA Rating | : | 5-20R |
| Number of Poles | : | 2-Pole |
| Number of Wires | : | 3-Wire |
| Phase | : | Single Phase |
| Size | : | 3.28 in x 1.41 in x 1.09 in |
| Special Features | : | Self Grounding |
| Standard | : | UL File No. E2186, Certified to CSA 22.2, No. 42 File 285, Fed. Spec. W-C-596, NEMA® WD-6 Compliant |
| Temperature Rating | : | Maximum continuous 75°C; minimum -40°C (w/o impact) |
| Type | : | Weather Resistant Duplex |
| Voltage Rating | : | 125 V |
| Wattage | : | 1875 W |
| Wire Size | : | #12 AWG to #10 AWG |
| Weight | : | 0.2 lb. |
| Width | : | 1.41 in |
| Connectivity | : | Back and Side Wired |
| Mounting Type | : | Screw Mount |
| Nema Rating | : | 5-20R |
| Number Of Poles | : | 2-Pole |
| Number Of Wires | : | 3-Wire |
| Operating Temperature | : | Maximum continuous 75°C and minimum -40°C without Impact |
| Style | : | Finder Groove Face |
| Class Code | : | A04 |
| Description - Invoice | : | PRO WR RECPT, DUP, 20A 125V, IV |
| Freight Class Code | : | 06168002 |
| Harmonization Code | : | 8536698000 |
| Image Actual Or Representative | : | A |
| MSDS Flag | : | No |
| Sub Class Code | : | A04A022 |
| Material - Mounting Hardware | : | Screw Mounting |
| Material | : | Thermoplastic/Composite |
| Base Unit of Measure | : | EA |
| BOX SIZE | : | 3.500x10.000x4.600 (in) |
| Carton - Gross Weight per Pack | : | 3.1 lb. |
| Carton - Number of Sub Packs | : | 10 |
| Carton - Pack Description | : | Carton |
| Carton - SCC-14 Next Lower Level Sub Pack | : | 783585358659 |
| Carton - Total Units | : | 10 EA |
| Case - Total Units | : | 100 EA |
| Case Weight | : | 20.000 lb. |
| Each - Pack Description | : | Each |
| Lowest Level UOM | : | Each |
Certifications | ||
| EU RoHS Indicator | : | No |
- Weather-resistance complies with national electrical code requirements
- Finder Groove Face
- Triple wipe contacts
- Compact design
- Self Grounding
Specifications
Buy American Compliant : Yes Country of Origin : US Dimensions : 3.28 in x 1.41 in x 1.09 in Each - Width : 1.900 in Height : 1.09 in Industry Standard(s) : UL File No. E2186, Certified to CSA 22.2, No. 42 File 285, Fed. Spec. W-C-596, NEMA® WD-6 Compliant Length : 3.28 in Amperage Rating : 20 A Application : Hubbell-Pro Extra Heavy Duty Color : Ivory Dielectric Strength : Withstands 2,000V minimum Mounting : Screw Mount NEMA Rating : 5-20R Number of Poles : 2-Pole Number of Wires : 3-Wire Phase : Single Phase Size : 3.28 in x 1.41 in x 1.09 in Special Features : Self Grounding Standard : UL File No. E2186, Certified to CSA 22.2, No. 42 File 285, Fed. Spec. W-C-596, NEMA® WD-6 Compliant Temperature Rating : Maximum continuous 75°C; minimum -40°C (w/o impact) Type : Weather Resistant Duplex Voltage Rating : 125 V Wattage : 1875 W Wire Size : #12 AWG to #10 AWG Weight : 0.2 lb. Width : 1.41 in Connectivity : Back and Side Wired Mounting Type : Screw Mount Nema Rating : 5-20R Number Of Poles : 2-Pole Number Of Wires : 3-Wire Operating Temperature : Maximum continuous 75°C and minimum -40°C without Impact Style : Finder Groove Face Class Code : A04 Description - Invoice : PRO WR RECPT, DUP, 20A 125V, IV Freight Class Code : 06168002 Harmonization Code : 8536698000 Image Actual Or Representative : A MSDS Flag : No Sub Class Code : A04A022 Material - Mounting Hardware : Screw Mounting Material : Thermoplastic/Composite Base Unit of Measure : EA BOX SIZE : 3.500x10.000x4.600 (in) Carton - Gross Weight per Pack : 3.1 lb. Carton - Number of Sub Packs : 10 Carton - Pack Description : Carton Carton - SCC-14 Next Lower Level Sub Pack : 783585358659 Carton - Total Units : 10 EA Case - Total Units : 100 EA Case Weight : 20.000 lb. Each - Pack Description : Each Lowest Level UOM : Each Certifications
EU RoHS Indicator : No - Downloads
