Straight Blade Devices, Receptacles, Single, Specification Grade, 2-Pole 3-Wire Grounding, 20A 250V, 6-20R, Orange, Single Pack
MFG #IG5461
$59.50 / E
EACH
EACH
Product Description:
Straight Blade Devices, Receptacles, Single, Specification Grade, 2-Pole 3-Wire Grounding, 20A 250V, 6-20R, Orange, Single Pack
HESCO Part Number
HUBIG5461
UPC
783585880501
Manufacturer Part Number
IG5461
Manufacturer
Hubbell Wiring Device
Straight Blade Devices, Receptacles, Single, Specification Grade, 2-Pole 3-Wire Grounding, 20A 250V, 6-20R, Orange, Single Pack
MFG #IG5461
Product Description:
Straight Blade Devices, Receptacles, Single, Specification Grade, 2-Pole 3-Wire Grounding, 20A 250V, 6-20R, Orange, Single Pack
HESCO Part Number
HUBIG5461
UPC
783585880501
Manufacturer Part Number
IG5461
Manufacturer
Hubbell Wiring Device
$59.50 / E
EACH
EACH
- Features
- Specifications
- Resources
- Triangle marking on face indicates isolated ground
- Patented bypass contact design
- Isolated Ground
Specifications
| Country of Origin | : | US |
| Dimensions | : | 3.28 in x 1.62 in x 1.19 in |
| Each - Width | : | 1.800 in |
| Height | : | 1.19 in |
| Industry Standard(s) | : | Certified to CSA 22.2, No. 42 File 285;Guide RTRT Fed Spec WC596G;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186 |
| Length | : | 3.28 in |
| Amperage Rating | : | 20 A |
| Application | : | Extra Heavy Duty |
| Color | : | Orange |
| Dielectric Strength | : | Withstands 2,000V minimum |
| NEMA Rating | : | 6-20R |
| Number of Poles | : | 2-Pole |
| Number of Wires | : | 3-Wire |
| Phase | : | Single Phase |
| Size | : | 3.28 in x 1.62 in x 1.19 in |
| Special Features | : | Isolated Ground |
| Standard | : | Certified to CSA 22.2, No. 42 File 285;Guide RTRT Fed Spec WC596G;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186 |
| Type | : | Single Receptacle |
| Voltage Rating | : | 250 V |
| Wattage | : | 5000 W |
| Wire Size | : | #14 AWG to #10 AWG |
| Weight | : | 0.2 lb. |
| Width | : | 1.62 in |
| Connectivity | : | Back and Side Wired Screw Terminals |
| Nema Rating | : | 6-20R |
| Number Of Poles | : | 2-Pole |
| Number Of Wires | : | 3-Wire |
| Operating Temperature | : | Maximum continuous 75°C and minimum -40°C without Impact |
| Style | : | Finder Groove Face |
| Class Code | : | A04 |
| Description - Invoice | : | SGL RCPT, IG, 20A 250V, 6-20R, OR |
| Freight Class Code | : | 06168002 |
| Harmonization Code | : | 8536690200 |
| Image Actual Or Representative | : | A |
| MSDS Flag | : | No |
| Sub Class Code | : | A04A060 |
| Material - Mounting Hardware | : | Screw Mounting |
| Material | : | Nylon |
| Base Unit of Measure | : | EA |
| BOX SIZE | : | 3.500x9.300x4.400 (in) |
| Carton - Gross Weight per Pack | : | 2.25 lb. |
| Carton - Number of Sub Packs | : | 10 |
| Carton - Pack Description | : | Carton |
| Carton - SCC-14 Next Lower Level Sub Pack | : | 783585880501 |
| Carton - Total Units | : | 10 EA |
| Case - Total Units | : | 100 EA |
| Case Weight | : | 23.850 lb. |
| Each - Pack Description | : | Each |
| Lowest Level UOM | : | Each |
Certifications | ||
| EU RoHS Indicator | : | Yes |
- Triangle marking on face indicates isolated ground
- Patented bypass contact design
- Isolated Ground
Specifications
Country of Origin : US Dimensions : 3.28 in x 1.62 in x 1.19 in Each - Width : 1.800 in Height : 1.19 in Industry Standard(s) : Certified to CSA 22.2, No. 42 File 285;Guide RTRT Fed Spec WC596G;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186 Length : 3.28 in Amperage Rating : 20 A Application : Extra Heavy Duty Color : Orange Dielectric Strength : Withstands 2,000V minimum NEMA Rating : 6-20R Number of Poles : 2-Pole Number of Wires : 3-Wire Phase : Single Phase Size : 3.28 in x 1.62 in x 1.19 in Special Features : Isolated Ground Standard : Certified to CSA 22.2, No. 42 File 285;Guide RTRT Fed Spec WC596G;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186 Type : Single Receptacle Voltage Rating : 250 V Wattage : 5000 W Wire Size : #14 AWG to #10 AWG Weight : 0.2 lb. Width : 1.62 in Connectivity : Back and Side Wired Screw Terminals Nema Rating : 6-20R Number Of Poles : 2-Pole Number Of Wires : 3-Wire Operating Temperature : Maximum continuous 75°C and minimum -40°C without Impact Style : Finder Groove Face Class Code : A04 Description - Invoice : SGL RCPT, IG, 20A 250V, 6-20R, OR Freight Class Code : 06168002 Harmonization Code : 8536690200 Image Actual Or Representative : A MSDS Flag : No Sub Class Code : A04A060 Material - Mounting Hardware : Screw Mounting Material : Nylon Base Unit of Measure : EA BOX SIZE : 3.500x9.300x4.400 (in) Carton - Gross Weight per Pack : 2.25 lb. Carton - Number of Sub Packs : 10 Carton - Pack Description : Carton Carton - SCC-14 Next Lower Level Sub Pack : 783585880501 Carton - Total Units : 10 EA Case - Total Units : 100 EA Case Weight : 23.850 lb. Each - Pack Description : Each Lowest Level UOM : Each Certifications
EU RoHS Indicator : Yes - Downloads
