Single Cable Rack Spacer
MFG #CRS1-X
$7.15Â /Â E
(Must order in increments of 10/E)
(Must order in increments of 10/E)
Product Description:
One space stackable cable rack spacer. Manufactured from black polycarbonate ABS blend. Use with CRS6 to fill width of ladder rack. Accepts cable up to .80" (20.3mm) diameter.
HESCO Part Number
PANCRS1X
UPC
074983791156
Manufacturer Part Number
CRS1-X
Manufacturer
Panduit
Single Cable Rack Spacer
MFG #CRS1-X
Product Description:
One space stackable cable rack spacer. Manufactured from black polycarbonate ABS blend. Use with CRS6 to fill width of ladder rack. Accepts cable up to .80" (20.3mm) diameter.
HESCO Part Number
PANCRS1X
UPC
074983791156
Manufacturer Part Number
CRS1-X
Manufacturer
Panduit
$7.15Â /Â E
(Must order in increments of 10/E)
(Must order in increments of 10/E)
- Features
- Specifications
- Resources
- Standards Met: RoHS Compliant
Packaging Details
| UPC | :Â Â | 07498379115 |
| GTIN Package | :Â Â | 00074983791156 |
| Standard Package Volume Ft3 | :Â Â | 0.0238 |
| Standard Package Weight Pounds | :Â Â | 0.1700 |
| Std Package Height In | :Â Â | 7 |
| Std Package Height MM | :Â Â | 177.8 |
| Std Package Length In | :Â Â | 8 |
| Std Package Length MM | :Â Â | 203.2 |
| Std Package Width In | :Â Â | 1.5 |
| Std Package Width MM | :Â Â | 38.1 |
| Std. Pkg. UOM | :Â Â | Piece |
| UOM EA PK | :Â Â | PK |
| Std. Pkg. Qty. | :Â Â | 10 |
| GTIN Carton | :Â Â | 50074983791151 |
| Standard Carton Volume Ft3 | :Â Â | 0.2380 |
| Standard Carton Weight Pounds | :Â Â | 1.7000 |
| Std Carton Height In | :Â Â | 5.9 |
| Std Carton Height MM | :Â Â | 149.86 |
| Std Carton Length In | :Â Â | 8.5 |
| Std Carton Length MM | :Â Â | 215.9 |
| Std Carton Width In | :Â Â | 8.2 |
| Std Carton Width MM | :Â Â | 208.28 |
| Std Ctn Qty | :Â Â | 100 |
| Min. Order UOM | :Â Â | Piece |
| EAN | :Â Â | 00074983791156 |
| REACH Status | :Â Â | N |
| ARRA Compliant | :Â Â | Y |
| Mercury Content Indicator | :Â Â | N |
| Hazardous Material Flag | :Â Â | N |
| Min Order Qty | :Â Â | 10.0000 |
| Pallet Quantity | :Â Â | 22,500 |
| Pallet Volume | :Â Â | 53.545573 |
| Pallet Weight | :Â Â | 382.5000 |
| RoHS Compliant | :Â Â | Compliant |
Specifications | ||
| Country of Origin | :Â Â | United States |
| Any Reason Not to Sell | :Â Â | N |
| Product Segment | :Â Â | DEFAULT |
| Compatible Hole Diameter (mm) | :Â Â | 20.3 |
| Overall Length (In.) | :Â Â | 0.81 |
| Product Type | :Â Â | Cable Rack Spacers |
| Overall Width (In.) | :Â Â | 1.13 |
| Color | :Â Â | Black |
| Overall Width (mm) | :Â Â | 28.7 |
| Material | :Â Â | Polycarbonate/ABS |
| Compatible Hole Diameter (In.) | :Â Â | 0.8 |
| Overall Length (mm) | :Â Â | 20.6 |
| Overall Height (In.) | :Â Â | 1 |
| Overall Height (mm) | :Â Â | 25.4 |
| Application | :Â Â | (1) To Eliminate Pinch Points, (2) Provides an Aesthetically Pleasing Installation, (3) Keeps Cables Segregated to Allow Installers to Quickly Identify the Location of the Cable |
| For Use With | :Â Â | CRS6 |
| Number of Positions | :Â Â | 1 |
