Mini-Com® 8-port DIN Rail Fiber Patch Panel
MFG #FDME8RG
$122.94 / E
EACH
EACH
Product Description:
The IndustrialNet™ 8-port DIN Rail Fiber Optic Patch Panel provides fiber protection for terminated distribution style cabling. It can be mounted to a standard 35mm DIN rail and locked in place with adjustable latches, which are designed to allow it to mount on a flat surface. This DIN rail mount enclosure includes a PG21 or ¾” NPT cable cord grip to secure fiber cables exiting the enclosure. It features a removable faceplate with four label pockets, labels, and covers for port identification.
HESCO Part Number
PANFDME8RG
UPC
074983640430
Manufacturer Part Number
FDME8RG
Manufacturer
Panduit
Mini-Com® 8-port DIN Rail Fiber Patch Panel
MFG #FDME8RG
Product Description:
The IndustrialNet™ 8-port DIN Rail Fiber Optic Patch Panel provides fiber protection for terminated distribution style cabling. It can be mounted to a standard 35mm DIN rail and locked in place with adjustable latches, which are designed to allow it to mount on a flat surface. This DIN rail mount enclosure includes a PG21 or ¾” NPT cable cord grip to secure fiber cables exiting the enclosure. It features a removable faceplate with four label pockets, labels, and covers for port identification.
HESCO Part Number
PANFDME8RG
UPC
074983640430
Manufacturer Part Number
FDME8RG
Manufacturer
Panduit
$122.94 / E
EACH
EACH
- Features
- Specifications
- Resources
- Product
- Standards Met: International Standard CEI IEC 60715; DIN EN 60715; DIN EN 50022;DIN 46277-3; BS 5584:1978:, IEC 60068 Environmental Testing; cULus. RoHS compliant
Packaging Details
| UPC | : | 07498364043 |
| GTIN Package | : | 00074983640430 |
| Standard Package Volume Ft3 | : | 0.1957 |
| Standard Package Weight Pounds | : | 1.2500 |
| Std Package Height In | : | 4.45 |
| Std Package Height MM | : | 113.03 |
| Std Package Length In | : | 10.1 |
| Std Package Length MM | : | 256.54 |
| Std Package Width In | : | 6.4 |
| Std Package Width MM | : | 162.56 |
| Std. Pkg. UOM | : | Piece |
| UOM EA PK | : | EA |
| Std. Pkg. Qty. | : | 1 |
| GTIN Carton | : | 50074983640435 |
| Standard Carton Volume Ft3 | : | 1.9566 |
| Standard Carton Weight Pounds | : | 12.5000 |
| Std Carton Height In | : | 14.45 |
| Std Carton Height MM | : | 367.03 |
| Std Carton Length In | : | 22.85 |
| Std Carton Length MM | : | 580.39 |
| Std Carton Width In | : | 10.75 |
| Std Carton Width MM | : | 273.05 |
| Std Ctn Qty | : | 10 |
| Min. Order UOM | : | Piece |
| EAN | : | 00074983640430 |
| REACH Status | : | N |
| ARRA Compliant | : | Y |
| Mercury Content Indicator | : | N |
| Hazardous Material Flag | : | N |
| Min Order Qty | : | 1.0000 |
| Pallet Quantity | : | 240 |
| Pallet Volume | : | 46.958019 |
| Pallet Weight | : | 300.0000 |
| RoHS Compliant | : | Compliant |
Specifications | ||
| Country of Origin | : | United States |
| Any Reason Not to Sell | : | N |
| Product Segment | : | IAI |
| Color | : | Gray |
| Overall Height (mm) | : | 193 |
| Overall Height (In.) | : | 7.6 |
| Product Type | : | Fiber Enclosure |
| Overall Depth (In.) | : | 4.76 |
| Mount Method | : | DIN Rail |
| Overall Depth (mm) | : | 122 |
| Application | : | Fiber Optic Cable Management |
| Overall Width (In.) | : | 2.88 |
| Overall Width (mm) | : | 73 |
| Sub Brand | : | IndustrialNet™ |
Case Studies
Case Studies 1
Installation Documents
Installation Documents 1
Downloads
Specification Sheets
Part Drawings
Part Drawings 1
Part Drawings 2
Installation Documents
Downloads
Part Drawings
Videos 1
- Standards Met: International Standard CEI IEC 60715; DIN EN 60715; DIN EN 50022;DIN 46277-3; BS 5584:1978:, IEC 60068 Environmental Testing; cULus. RoHS compliant
Packaging Details
UPC : 07498364043 GTIN Package : 00074983640430 Standard Package Volume Ft3 : 0.1957 Standard Package Weight Pounds : 1.2500 Std Package Height In : 4.45 Std Package Height MM : 113.03 Std Package Length In : 10.1 Std Package Length MM : 256.54 Std Package Width In : 6.4 Std Package Width MM : 162.56 Std. Pkg. UOM : Piece UOM EA PK : EA Std. Pkg. Qty. : 1 GTIN Carton : 50074983640435 Standard Carton Volume Ft3 : 1.9566 Standard Carton Weight Pounds : 12.5000 Std Carton Height In : 14.45 Std Carton Height MM : 367.03 Std Carton Length In : 22.85 Std Carton Length MM : 580.39 Std Carton Width In : 10.75 Std Carton Width MM : 273.05 Std Ctn Qty : 10 Min. Order UOM : Piece EAN : 00074983640430 REACH Status : N ARRA Compliant : Y Mercury Content Indicator : N Hazardous Material Flag : N Min Order Qty : 1.0000 Pallet Quantity : 240 Pallet Volume : 46.958019 Pallet Weight : 300.0000 RoHS Compliant : Compliant Specifications
Country of Origin : United States Any Reason Not to Sell : N Product Segment : IAI Color : Gray Overall Height (mm) : 193 Overall Height (In.) : 7.6 Product Type : Fiber Enclosure Overall Depth (In.) : 4.76 Mount Method : DIN Rail Overall Depth (mm) : 122 Application : Fiber Optic Cable Management Overall Width (In.) : 2.88 Overall Width (mm) : 73 Sub Brand : IndustrialNet™ - Case Studies
Case Studies 1
Installation Documents
Installation Documents 1
Downloads
Specification Sheets
Part Drawings
Part Drawings 1
Part Drawings 2 - Videos 1
