Wet-Shrink™ HST0.4-3-QY Heat Shrink
MFG #HST0.4-3-QY
$7.21 / E
(Must order in increments of 25/E)
(Must order in increments of 25/E)
Product Description:
Thick wall adhesive lined, .4" (10.2mm) diameter, 3.0" (76.2mm) length, adhesive lined black cross-linked polyolefin, 25 pc. package quantity.
HESCO Part Number
PANHST043QY
UPC
074983107087
Manufacturer Part Number
HST0.4-3-QY
Manufacturer
Panduit
Wet-Shrink™ HST0.4-3-QY Heat Shrink
MFG #HST0.4-3-QY
Product Description:
Thick wall adhesive lined, .4" (10.2mm) diameter, 3.0" (76.2mm) length, adhesive lined black cross-linked polyolefin, 25 pc. package quantity.
HESCO Part Number
PANHST043QY
UPC
074983107087
Manufacturer Part Number
HST0.4-3-QY
Manufacturer
Panduit
$7.21 / E
(Must order in increments of 25/E)
(Must order in increments of 25/E)
- Features
- Specifications
- Resources
- Product
- Standards Met: UL Recognized, UL Listed, CSA Approved, MIL SPEC
Specifications
| Country of Origin | : | Canada |
| Any Reason Not to Sell | : | N |
| Product Segment | : | IEI |
| Nominal Diameter (mm) | : | 10.2 |
| Nominal Recovered Wall Thickness (mm) | : | 2 |
| Maximum Recovered Inside Diameter (mm) | : | 4.1 |
| Adhesive Lined | : | Yes |
| Nominal Diameter (In.) | : | 0.4 |
| Overall Length (m) | : | 0.1 |
| Minimum Expanded Inside Diameter (In.) | : | 0.4 |
| Shrink Ratio | : | 3:1 |
| Product Type | : | Heat Shrink Tubing |
| Minimum Operating Temperature (°F) | : | -67 |
| Maximum Operating Temperature (°F) | : | 230 |
| Shrink Temperature (°C) | : | 120 |
| Minimum Operating Temperature (°C) | : | -55 |
| Maximum Operating Temperature (°C) | : | 110 |
| Nominal Recovered Wall Thickness (In.) | : | 0.08 |
| Application | : | For Wet Locations; Insulating and protecting wires and cables; Suitable for direct burial |
| Overall Length (In.) | : | 3 |
| Color | : | Black |
| Overall Length (ft.) | : | 0.22 |
| Shrink Temperature (°F) | : | 248 |
| Sub Brand | : | Wet-Shrink™ |
| Overall Length (mm) | : | 76.2 |
| Minimum Expanded Inside Diameter (mm) | : | 10.2 |
| Material | : | Cross-Linked Polyolefin |
| Maximum Recovered Inside Diameter (In.) | : | 0.16 |
| Finish/Coating | : | Adhesive-Lined |
Packaging Details | ||
| UPC | : | 07498310708 |
| GTIN Package | : | 00074983107087 |
| Standard Package Volume Ft3 | : | 0.0611 |
| Standard Package Weight Pounds | : | 0.3850 |
| Std Package Height In | : | 1.5 |
| Std Package Height MM | : | 38.1 |
| Std Package Length In | : | 9 |
| Std Package Length MM | : | 228.6 |
| Std Package Width In | : | 8 |
| Std Package Width MM | : | 203.2 |
| Std. Pkg. UOM | : | Piece |
| UOM EA PK | : | PK |
| Std. Pkg. Qty. | : | 25 |
| GTIN Carton | : | 50074983107082 |
| Standard Carton Volume Ft3 | : | 0.2446 |
| Standard Carton Weight Pounds | : | 1.5400 |
| Std Carton Height In | : | 5.7 |
| Std Carton Height MM | : | 144.78 |
| Std Carton Length In | : | 8.6 |
| Std Carton Length MM | : | 218.44 |
| Std Carton Width In | : | 8.1 |
| Std Carton Width MM | : | 205.74 |
| Std Ctn Qty | : | 100 |
| Min. Order UOM | : | Piece |
| EAN | : | 00074983107087 |
| REACH Status | : | N |
| ARRA Compliant | : | Y |
| Mercury Content Indicator | : | N |
| Hazardous Material Flag | : | N |
| Min Order Qty | : | 25.0000 |
| Pallet Quantity | : | 20,000 |
| Pallet Volume | : | 48.914211 |
| Pallet Weight | : | 308.0000 |
| RoHS Compliant | : | Compliant |
