Dry-Shrink™ HSTTPN150-CC Heat Shrink
MFG #HSTTPN150-CC
$945.25 / E
EACH
EACH
Product Description:
Crystal clear thin wall PVC heat shrink, 1.5" (38.1mm) diameter, clear polyvinyl chloride, 100 ft. (30.5m) per reel.
HESCO Part Number
PANHSTTPN150CC
UPC
074983813506
Manufacturer Part Number
HSTTPN150-CC
Manufacturer
Panduit
Dry-Shrink™ HSTTPN150-CC Heat Shrink
MFG #HSTTPN150-CC
Product Description:
Crystal clear thin wall PVC heat shrink, 1.5" (38.1mm) diameter, clear polyvinyl chloride, 100 ft. (30.5m) per reel.
HESCO Part Number
PANHSTTPN150CC
UPC
074983813506
Manufacturer Part Number
HSTTPN150-CC
Manufacturer
Panduit
$945.25 / E
EACH
EACH
- Features
- Specifications
- Resources
- Product
- Standards Met: UL Recognized, CSA Approved, MIL SPEC
Specifications
| Country of Origin | : | United States |
| Any Reason Not to Sell | : | N |
| Product Segment | : | IEI |
| Shrink Ratio | : | 2:1 |
| Maximum Operating Temperature (°C) | : | 105 |
| Shrink Temperature (°F) | : | 212 |
| Overall Length (m) | : | 30.48 |
| Product Type | : | Heat Shrink Tubing |
| Overall Length (In.) | : | 1200 |
| Nominal Diameter (mm) | : | 38.1 |
| Application | : | For Dry Locations |
| Color | : | Clear |
| Shrink Temperature (°C) | : | 100 |
| Minimum Expanded Inside Diameter (In.) | : | 1.39 |
| Sub Brand | : | Dry-Shrink™ |
| Nominal Recovered Wall Thickness (In.) | : | 0.03 |
| Minimum Expanded Inside Diameter (mm) | : | 35.4 |
| Minimum Operating Temperature (°F) | : | -4 |
| Adhesive Lined | : | No |
| Overall Length (ft.) | : | 100 |
| Nominal Recovered Wall Thickness (mm) | : | 0.8 |
| Maximum Recovered Inside Diameter (mm) | : | 19.1 |
| Overall Length (mm) | : | 30480 |
| Nominal Diameter (In.) | : | 1.4 |
| Maximum Recovered Inside Diameter (In.) | : | 0.75 |
| Maximum Operating Temperature (°F) | : | 221 |
| Material | : | PVC |
| Minimum Operating Temperature (°C) | : | -20 |
Packaging Details | ||
| UPC | : | 07498381350 |
| GTIN Package | : | 00074983813506 |
| Standard Package Volume Ft3 | : | 1.2390 |
| Standard Package Weight Pounds | : | 3.7500 |
| Std Package Height In | : | 9.5 |
| Std Package Height MM | : | 241.3 |
| Std Package Length In | : | 21.5 |
| Std Package Length MM | : | 546.1 |
| Std Package Width In | : | 21.5 |
| Std Package Width MM | : | 546.1 |
| Std. Pkg. UOM | : | Roll |
| UOM EA PK | : | EA |
| Std. Pkg. Qty. | : | 1 |
| GTIN Carton | : | 50074983813501 |
| Standard Carton Volume Ft3 | : | 2.4780 |
| Standard Carton Weight Pounds | : | 7.5000 |
| Std Carton Height In | : | 8.9 |
| Std Carton Height MM | : | 226.06 |
| Std Carton Length In | : | 19.1 |
| Std Carton Length MM | : | 485.14 |
| Std Carton Width In | : | 18.4 |
| Std Carton Width MM | : | 467.36 |
| Std Ctn Qty | : | 2 |
| Min. Order UOM | : | Roll |
| EAN | : | 00074983813506 |
| REACH Status | : | N |
| ARRA Compliant | : | Y |
| Mercury Content Indicator | : | N |
| Hazardous Material Flag | : | N |
| Min Order Qty | : | 1.0000 |
| Pallet Quantity | : | 96 |
| Pallet Volume | : | 118.945421 |
| Pallet Weight | : | 360.0000 |
| RoHS Compliant | : | Compliant |
