CuLugSBW,2Hole,#8AWG,1/4,.75,45°PKG50
MFG #LCD8-14BH-L
$13.95 / E
EACH
EACH
Product Description:
Two-hole, standard barrel lug with window, #8 AWG wire, 1/4 stud hole, .75 hole spacing, 45° angle tongue..
HESCO Part Number
PANLCD814BHL
UPC
074983566594
Manufacturer Part Number
LCD8-14BH-L
Manufacturer
Panduit
CuLugSBW,2Hole,#8AWG,1/4,.75,45°PKG50
MFG #LCD8-14BH-L
Product Description:
Two-hole, standard barrel lug with window, #8 AWG wire, 1/4 stud hole, .75 hole spacing, 45° angle tongue..
HESCO Part Number
PANLCD814BHL
UPC
074983566594
Manufacturer Part Number
LCD8-14BH-L
Manufacturer
Panduit
$13.95 / E
EACH
EACH
- Features
- Specifications
- Resources
- Standards Met: CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, NEBS Level 3
Specifications
| Country of Origin | : | Mexico |
| Any Reason Not to Sell | : | N |
| Product Segment | : | IEI |
| Overall Length (mm) | : | 49.3 |
| Overall Length (In.) | : | 1.94 |
| Wire Strip Length (In.) | : | 5/8 |
| UL Temperature Rating (°C) | : | 90 |
| Tongue Width (In.) | : | 0.48 |
| Panduit Die Index Number | : | P21 |
| CSA Temperature Rating (°C) | : | 90 |
| Color Code | : | Red |
| Stud Hole Spacing (In.) | : | 3/4 |
| Stud Hole Spacing (mm) | : | 19.1 |
| Barrel Length (In.) | : | 0.56 |
| Tongue Type | : | Standard |
| Stud Hole Size (mm) | : | 6.4 |
| Barrel Type | : | Standard |
| Tongue Thickness (mm) | : | 1.8 |
| Finish/Coating | : | Tin-Plated |
| Stud Hole Size (In.) | : | 1/4 |
| T & B Die Index Number | : | 21 |
| Sub Brand | : | Pan-Lug™ |
| Tongue Width (mm) | : | 12.2 |
| Tongue Angle | : | 45° |
| Tongue Thickness (In.) | : | 0.07 |
| Product Type | : | Compression Lug |
| Base Material | : | Copper |
| Maximum Voltage (kV) | : | 35 |
| Burndy Die Index Number | : | 49 |
| Barrel Length (mm) | : | 14.2 |
| Note | : | Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
| Wire Strip Length (mm) | : | 15.9 |
| Barrel Entry | : | Beveled |
| Inspection Window | : | Yes |
| Number of Stud Holes | : | 2 |
| Copper Conductor Size | : | 8 AWG |
Packaging Details | ||
| UPC | : | 07498356659 |
| GTIN Package | : | 00074983566594 |
| Standard Package Volume Ft3 | : | 0.0296 |
| Standard Package Weight Pounds | : | 1.0500 |
| Std Package Height In | : | 3.3 |
| Std Package Height MM | : | 83.82 |
| Std Package Length In | : | 4.7 |
| Std Package Length MM | : | 119.38 |
| Std Package Width In | : | 3.3 |
| Std Package Width MM | : | 83.82 |
| Std. Pkg. UOM | : | Piece |
| UOM EA PK | : | PK |
| Std. Pkg. Qty. | : | 50 |
| Standard Carton Volume Ft3 | : | 0.0000 |
| Standard Carton Weight Pounds | : | 0.0000 |
| Std Ctn Qty | : | 0 |
| Min. Order UOM | : | Piece |
| EAN | : | 00074983566594 |
| REACH Status | : | N |
| ARRA Compliant | : | Y |
| Mercury Content Indicator | : | N |
| Hazardous Material Flag | : | N |
| Min Order Qty | : | 50.0000 |
| Pallet Quantity | : | 0 |
| Pallet Volume | : | 0.000000 |
| Pallet Weight | : | 0.0000 |
| RoHS Compliant | : | Compliant |
- Standards Met: CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, NEBS Level 3
Specifications
Country of Origin : Mexico Any Reason Not to Sell : N Product Segment : IEI Overall Length (mm) : 49.3 Overall Length (In.) : 1.94 Wire Strip Length (In.) : 5/8 UL Temperature Rating (°C) : 90 Tongue Width (In.) : 0.48 Panduit Die Index Number : P21 CSA Temperature Rating (°C) : 90 Color Code : Red Stud Hole Spacing (In.) : 3/4 Stud Hole Spacing (mm) : 19.1 Barrel Length (In.) : 0.56 Tongue Type : Standard Stud Hole Size (mm) : 6.4 Barrel Type : Standard Tongue Thickness (mm) : 1.8 Finish/Coating : Tin-Plated Stud Hole Size (In.) : 1/4 T & B Die Index Number : 21 Sub Brand : Pan-Lug™ Tongue Width (mm) : 12.2 Tongue Angle : 45° Tongue Thickness (In.) : 0.07 Product Type : Compression Lug Base Material : Copper Maximum Voltage (kV) : 35 Burndy Die Index Number : 49 Barrel Length (mm) : 14.2 Note : Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V Wire Strip Length (mm) : 15.9 Barrel Entry : Beveled Inspection Window : Yes Number of Stud Holes : 2 Copper Conductor Size : 8 AWG Packaging Details
UPC : 07498356659 GTIN Package : 00074983566594 Standard Package Volume Ft3 : 0.0296 Standard Package Weight Pounds : 1.0500 Std Package Height In : 3.3 Std Package Height MM : 83.82 Std Package Length In : 4.7 Std Package Length MM : 119.38 Std Package Width In : 3.3 Std Package Width MM : 83.82 Std. Pkg. UOM : Piece UOM EA PK : PK Std. Pkg. Qty. : 50 Standard Carton Volume Ft3 : 0.0000 Standard Carton Weight Pounds : 0.0000 Std Ctn Qty : 0 Min. Order UOM : Piece EAN : 00074983566594 REACH Status : N ARRA Compliant : Y Mercury Content Indicator : N Hazardous Material Flag : N Min Order Qty : 50.0000 Pallet Quantity : 0 Pallet Volume : 0.000000 Pallet Weight : 0.0000 RoHS Compliant : Compliant - Installation Documents
Installation Documents 1
