Pan-Steel® MLT6DSH-Q Cable Cleat, MLT Strap, 304 SS, Single/Trefoil/Quad, 41.5"
MFG #MLT6DSH-Q
$9.45 / E
(Must order in increments of 100/E)
(Must order in increments of 100/E)
Product Description:
The MLT6DSH-Q self-locking cable cleat speeds up installation with a unique self-locking head that secures into any position along the band's length. The smooth and safe cable banding passes through the head twice, providing additional strength in short circuit applications. The variable design is compatible with quad, trefoil, and multicore cables and certified to IEC61914:2015, tested up to 75.1kA peak fault current. Features 304 AISI SS, 5340N tensile strength, 152mm bundle capacity.
HESCO Part Number
PANMLT6DSHQ
UPC
074983446032
Manufacturer Part Number
MLT6DSH-Q
Manufacturer
Panduit
Pan-Steel® MLT6DSH-Q Cable Cleat, MLT Strap, 304 SS, Single/Trefoil/Quad, 41.5"
MFG #MLT6DSH-Q
Product Description:
The MLT6DSH-Q self-locking cable cleat speeds up installation with a unique self-locking head that secures into any position along the band's length. The smooth and safe cable banding passes through the head twice, providing additional strength in short circuit applications. The variable design is compatible with quad, trefoil, and multicore cables and certified to IEC61914:2015, tested up to 75.1kA peak fault current. Features 304 AISI SS, 5340N tensile strength, 152mm bundle capacity.
HESCO Part Number
PANMLT6DSHQ
UPC
074983446032
Manufacturer Part Number
MLT6DSH-Q
Manufacturer
Panduit
$9.45 / E
(Must order in increments of 100/E)
(Must order in increments of 100/E)
- Features
- Specifications
- Resources
- Product
- No
Packaging Details
| UPC | : | 07498344603 |
| GTIN Package | : | 00074983446032 |
| Standard Package Volume Ft3 | : | 0.2803 |
| Standard Package Weight Pounds | : | 3.4425 |
| Std Package Height In | : | .5 |
| Std Package Height MM | : | 12.7 |
| Std Package Length In | : | 48 |
| Std Package Length MM | : | 1219.2 |
| Std Package Width In | : | 5.8 |
| Std Package Width MM | : | 147.32 |
| Std. Pkg. UOM | : | Piece |
| UOM EA PK | : | PK |
| Std. Pkg. Qty. | : | 25 |
| GTIN Carton | : | 50074983446037 |
| Standard Carton Volume Ft3 | : | 1.4013 |
| Standard Carton Weight Pounds | : | 17.2125 |
| Std Carton Height In | : | 6.4 |
| Std Carton Height MM | : | 162.56 |
| Std Carton Length In | : | 23.5 |
| Std Carton Length MM | : | 596.9 |
| Std Carton Width In | : | 16.1 |
| Std Carton Width MM | : | 408.94 |
| Std Ctn Qty | : | 125 |
| Min. Order UOM | : | Piece |
| EAN | : | 00074983446032 |
| REACH Status | : | N |
| California Pro65 Cancer | : | No |
| ARRA Compliant | : | Y |
| Mercury Content Indicator | : | N |
| Hazardous Material Flag | : | N |
| Min Order Qty | : | 100.0000 |
| Pallet Quantity | : | 3,500 |
| Pallet Volume | : | 39.236296 |
| Pallet Weight | : | 481.9500 |
| RoHS Compliant | : | Compliant |
Specifications | ||
| Country of Origin | : | United States |
| Any Reason Not to Sell | : | N |
| Product Segment | : | IEI |
| Color | : | Natural |
| Minimum Loop Tensile Strength (N) | : | 5.34 |
| Minimum Installation Temperature (°F) | : | -76 |
| Sub Brand | : | Pan-Steel® |
| Maximum Operating Temperature (°F) | : | 1 |
| Minimum Installation Temperature (°C) | : | -60 |
| Body Thickness (mm) | : | 0.4 |
| Overall Length (In.) | : | 41.5 |
| Application | : | General |
| Material | : | Stainless Steel Type 304 |
| Minimum Operating Temperature (°C) | : | -60 |
| Maximum Bundle Diameter (In.) | : | 6 |
| Product Type | : | Self-Locking Cable Cleat |
| Body Width (mm) | : | 15.9 |
| Maximum Bundle Diameter (mm) | : | 152 |
| Environment | : | Indoor/Outdoor |
| Body Width (In.) | : | 0.62 |
| Overall Length (mm) | : | 1.1 |
| Maximum Operating Temperature (°C) | : | 538 |
| Body Thickness (In.) | : | 0.015 |
| Minimum Operating Temperature (°F) | : | -76 |
| Minimum Loop Tensile Strength (lb) | : | 1200 |
