Pan-Ty® PLT4S-C3 Cable Tie, Orange, PA6.6, 14.5"L, 50lb, PK100
MFG #PLT4S-C3
$0.73 / E
(Must order in increments of 1000/E)
(Must order in increments of 1000/E)
Product Description:
Pan-Ty® locking tie, standard cross section, 14.5 (368mm) length, nylon 6.6, orange, standard package.
HESCO Part Number
PANPLT4SC3
UPC
074983547746
Manufacturer Part Number
PLT4S-C3
Manufacturer
Panduit
Pan-Ty® PLT4S-C3 Cable Tie, Orange, PA6.6, 14.5"L, 50lb, PK100
MFG #PLT4S-C3
Product Description:
Pan-Ty® locking tie, standard cross section, 14.5 (368mm) length, nylon 6.6, orange, standard package.
HESCO Part Number
PANPLT4SC3
UPC
074983547746
Manufacturer Part Number
PLT4S-C3
Manufacturer
Panduit
$0.73 / E
(Must order in increments of 1000/E)
(Must order in increments of 1000/E)
- Features
- Specifications
- Resources
- Product
- No
- Standards Met: CSA Certified, UL Recognized (File #E56854), UL 62275 Compliant (Type 2S, 21S), AH-2, RoHS Compliant
Specifications
| Country of Origin | : | Denmark, Malaysia |
| Any Reason Not to Sell | : | N |
| Product Segment | : | IEI |
| Overall Length (mm) | : | 368 |
| Minimum Bundle Diameter (In.) | : | 0.06 |
| Body Width (In.) | : | 0.19 |
| Maximum Operating Temperature (°C) | : | 85 |
| Overall Length (In.) | : | 14.5 |
| Body Thickness (In.) | : | 0.052 |
| For Use With | : | GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PTH |
| Color | : | Orange |
| Body Width (mm) | : | 4.8 |
| Minimum Loop Tensile Strength (N) | : | 222 |
| Minimum Loop Tensile Strength (lb) | : | 50 |
| Minimum Operating Temperature (°F) | : | -76 |
| Environment | : | Plenum |
| Body Thickness (mm) | : | 1.3 |
| Maximum Bundle Diameter (mm) | : | 101.6 |
| Application | : | General |
| Maximum Operating Temperature (°F) | : | 185 |
| Maximum Bundle Diameter (In.) | : | 4 |
| Material | : | Nylon 6.6 |
| Military Cross Reference Number | : | MS3367-2-3 |
| Minimum Bundle Diameter (mm) | : | 1.5 |
| Minimum Installation Temperature (°F) | : | -4 |
| Product Type | : | Premium Cable Tie |
| Minimum Operating Temperature (°C) | : | -60 |
| Minimum Installation Temperature (°C) | : | -20 |
| Material Description | : | Nylon 6.6 |
Packaging Details | ||
| UPC | : | 07498354774 |
| GTIN Package | : | 00074983547746 |
| Standard Package Volume Ft3 | : | 0.0556 |
| Standard Package Weight Pounds | : | 0.7000 |
| Std Package Height In | : | 1.4 |
| Std Package Height MM | : | 35.56 |
| Std Package Length In | : | 16.6 |
| Std Package Length MM | : | 421.64 |
| Std Package Width In | : | 5.7 |
| Std Package Width MM | : | 144.78 |
| Std. Pkg. UOM | : | Piece |
| UOM EA PK | : | PK |
| Std. Pkg. Qty. | : | 100 |
| GTIN Carton | : | 50074983547741 |
| Standard Carton Volume Ft3 | : | 0.5563 |
| Standard Carton Weight Pounds | : | 7.0000 |
| Std Carton Height In | : | 6 |
| Std Carton Height MM | : | 152.4 |
| Std Carton Length In | : | 16.7 |
| Std Carton Length MM | : | 424.18 |
| Std Carton Width In | : | 8.85 |
| Std Carton Width MM | : | 224.79 |
| Std Ctn Qty | : | 1000 |
| Min. Order UOM | : | Piece |
| EAN | : | 00074983547746 |
| REACH Status | : | N |
| California Pro65 Cancer | : | No |
| ARRA Compliant | : | Y |
| Mercury Content Indicator | : | N |
| Lead Content Indicator | : | N |
| Restricted Use of Hazardous Substances | : | N |
| Hazardous Material Flag | : | N |
| Min Order Qty | : | 1,000.0000 |
| Pallet Quantity | : | 96,000 |
| Pallet Volume | : | 53.400842 |
| Pallet Weight | : | 672.0000 |
| RoHS Compliant | : | Compliant |
Part Drawings
Part Drawings 1
Part Drawings 2
Cross References
Cross References 1
Videos
Selection Guides
Selection Guides 1
Part Drawings 1Part Drawings 2Cross References
Cross References 1Videos
Selection Guides
Selection Guides 1Videos 1
- No
- Standards Met: CSA Certified, UL Recognized (File #E56854), UL 62275 Compliant (Type 2S, 21S), AH-2, RoHS Compliant
Specifications
Country of Origin : Denmark, Malaysia Any Reason Not to Sell : N Product Segment : IEI Overall Length (mm) : 368 Minimum Bundle Diameter (In.) : 0.06 Body Width (In.) : 0.19 Maximum Operating Temperature (°C) : 85 Overall Length (In.) : 14.5 Body Thickness (In.) : 0.052 For Use With : GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PTH Color : Orange Body Width (mm) : 4.8 Minimum Loop Tensile Strength (N) : 222 Minimum Loop Tensile Strength (lb) : 50 Minimum Operating Temperature (°F) : -76 Environment : Plenum Body Thickness (mm) : 1.3 Maximum Bundle Diameter (mm) : 101.6 Application : General Maximum Operating Temperature (°F) : 185 Maximum Bundle Diameter (In.) : 4 Material : Nylon 6.6 Military Cross Reference Number : MS3367-2-3 Minimum Bundle Diameter (mm) : 1.5 Minimum Installation Temperature (°F) : -4 Product Type : Premium Cable Tie Minimum Operating Temperature (°C) : -60 Minimum Installation Temperature (°C) : -20 Material Description : Nylon 6.6 Packaging Details
UPC : 07498354774 GTIN Package : 00074983547746 Standard Package Volume Ft3 : 0.0556 Standard Package Weight Pounds : 0.7000 Std Package Height In : 1.4 Std Package Height MM : 35.56 Std Package Length In : 16.6 Std Package Length MM : 421.64 Std Package Width In : 5.7 Std Package Width MM : 144.78 Std. Pkg. UOM : Piece UOM EA PK : PK Std. Pkg. Qty. : 100 GTIN Carton : 50074983547741 Standard Carton Volume Ft3 : 0.5563 Standard Carton Weight Pounds : 7.0000 Std Carton Height In : 6 Std Carton Height MM : 152.4 Std Carton Length In : 16.7 Std Carton Length MM : 424.18 Std Carton Width In : 8.85 Std Carton Width MM : 224.79 Std Ctn Qty : 1000 Min. Order UOM : Piece EAN : 00074983547746 REACH Status : N California Pro65 Cancer : No ARRA Compliant : Y Mercury Content Indicator : N Lead Content Indicator : N Restricted Use of Hazardous Substances : N Hazardous Material Flag : N Min Order Qty : 1,000.0000 Pallet Quantity : 96,000 Pallet Volume : 53.400842 Pallet Weight : 672.0000 RoHS Compliant : Compliant - Part DrawingsPart Drawings 1Part Drawings 2
Cross ReferencesCross References 1
Videos
Selection GuidesSelection Guides 1 - Videos 1
