T&B 54152-TB 1/0AWG PNK 1H COP LUG
MFG #54152-TB
$22.89Â /Â E
(Must order in increments of 10/E)
(Must order in increments of 10/E)
Product Description:
Copper One-Hole Lug - Straight Standard Barrel - max 35KV, 1/0 AWG Wire, 1/4" Bolt Size, Tin Plated with Inspection Hole, Pink 42
HESCO Part Number
TB54152TB
UPC
78621054152
Manufacturer Part Number
54152-TB
Manufacturer
Thomas & Betts
T&B 54152-TB 1/0AWG PNK 1H COP LUG
MFG #54152-TB
Product Description:
Copper One-Hole Lug - Straight Standard Barrel - max 35KV, 1/0 AWG Wire, 1/4" Bolt Size, Tin Plated with Inspection Hole, Pink 42
HESCO Part Number
TB54152TB
UPC
78621054152
Manufacturer Part Number
54152-TB
Manufacturer
Thomas & Betts
$22.89Â /Â E
(Must order in increments of 10/E)
(Must order in increments of 10/E)
- Features
- Specifications
- Resources
- Dimensions given for reference only. Dimensions may vary up to .030.
Packaging
| Inner Package | :Â Â | 10 |
| Package Length | :Â Â | 12.5 |
| Order Multiple | :Â Â | 10 |
| Package Width | :Â Â | 6.3 |
| Package Height | :Â Â | 3.9 |
| Outer Package | :Â Â | 100 |
| T&B Sold in UOM | :Â Â | Each |
| T&B Weight Per UOM | :Â Â | 5.56 lbs. per 100 |
Dimension Information | ||
| F (inches) | :Â Â | 0.25 |
| A (inches) | :Â Â | 1.6 |
| E (inches) | :Â Â | 0.52 |
| D (inches) | :Â Â | 0.13 |
| B (inches) | :Â Â | 0.65 |
| C (inches) | :Â Â | 0.75 |
General | ||
| Stud Size | :Â Â | 1/4 |
| Barrel Shape | :Â Â | Standard |
| Tongue Angle | :Â Â | Straight |
| Number of Studs | :Â Â | 1 |
| Die Code | :Â Â | 42 |
| Peep Hole | :Â Â | Y |
| Die Color | :Â Â | Pink |
| Finish | :Â Â | Tin-Plated |
| Hole Shape | :Â Â | Round |
| Material | :Â Â | Copper |
| Wire Size | :Â Â | 1/0 AWG |
| Barrel Length | :Â Â | Standard |
| Tongue Width | :Â Â | Standard |
| Marking | :Â Â | Standard |
Certifications | ||
| RoHS Compliance | :Â Â | Yes |
