Conduit Bodies, Covers & Gaskets
MFG #BLB-7
$364.86Â /Â E
EACH
EACH
Product Description:
2-1/2 inch Set Screw Die Cast Aluminum Conduit Body with Back-Opening. For Use with EMT Conduit.
HESCO Part Number
REDBLB7
UPC
04226933340
Manufacturer Part Number
BLB-7
Manufacturer
Thomas & Betts
Conduit Bodies, Covers & Gaskets
MFG #BLB-7
Product Description:
2-1/2 inch Set Screw Die Cast Aluminum Conduit Body with Back-Opening. For Use with EMT Conduit.
HESCO Part Number
REDBLB7
UPC
04226933340
Manufacturer Part Number
BLB-7
Manufacturer
Thomas & Betts
$364.86Â /Â E
EACH
EACH
- Features
- Specifications
- Resources
- Smooth throats for easy wire pulling
- Retained stainless steel cover screws
- UL
- Spacious, accessible wiring chamber provides a convenient location to pull conductors and make splices.
- For use with EMT conduit
- Shipped with 1-die cast aluminum cover
Dimension Information
| D (inches) | :Â Â | 3 7/16 |
| A (inches) | :Â Â | 9 1/2 |
| C (inches) | :Â Â | 3 1/8 |
| F (inches) | :Â Â | 4 1/2 |
| B (inches) | :Â Â | 9 13/16 |
| E (inches) | :Â Â | 8 |
Certifications | ||
| RoHS Compliance | :Â Â | Yes |
Packaging | ||
| T&B Weight Per UOM | :Â Â | 4.27 lbs. Each |
| Package Height | :Â Â | 5.69 |
| Outer Package | :Â Â | 1 |
| Package Width | :Â Â | 6.75 |
| T&B Sold in UOM | :Â Â | Each |
| Package Length | :Â Â | 13.56 |
General | ||
| Volume (cu.in.) | :Â Â | 190 |
| Trade Size (inches) | :Â Â | 2-1/2 |
| Material | :Â Â | Die Cast Aluminum |
Accessories & Components | ||
| Cover-Die Cast | :Â Â | CV-6 |
| Gasket-Composition | :Â Â | GKV-6 |
| Gasket-Neoprene | :Â Â | GKN-6 |
- Smooth throats for easy wire pulling
- Retained stainless steel cover screws
- UL
- Spacious, accessible wiring chamber provides a convenient location to pull conductors and make splices.
- For use with EMT conduit
- Shipped with 1-die cast aluminum cover
Dimension Information
D (inches) :Â Â 3 7/16 A (inches) :Â Â 9 1/2 C (inches) :Â Â 3 1/8 F (inches) :Â Â 4 1/2 B (inches) :Â Â 9 13/16 E (inches) :Â Â 8 Certifications
RoHS Compliance :Â Â Yes Packaging
T&B Weight Per UOM :Â Â 4.27 lbs. Each Package Height :Â Â 5.69 Outer Package :Â Â 1 Package Width :Â Â 6.75 T&B Sold in UOM :Â Â Each Package Length :Â Â 13.56 General
Volume (cu.in.) :Â Â 190 Trade Size (inches) :Â Â 2-1/2 Material :Â Â Die Cast Aluminum Accessories & Components
Cover-Die Cast :Â Â CV-6 Gasket-Composition :Â Â GKV-6 Gasket-Neoprene :Â Â GKN-6 - Certifications
RoHS Compliance
