Service Entrance Splices
MFG #IKL35
$15.72Â /Â E
EACH
EACH
Product Description:
Aluminum 5-1/2 inch Service Entrance Compression Splice for Wire Range - End A: 1/0 ASCR, 2/0 Str., 1/0 Str. Compact, Red, End B: 2 ASCR, 1-2 Str., Red, Die: 840
HESCO Part Number
BLBIKL35
UPC
78378605021
Manufacturer Part Number
IKL35
Manufacturer
Thomas & Betts
Service Entrance Splices
MFG #IKL35
Product Description:
Aluminum 5-1/2 inch Service Entrance Compression Splice for Wire Range - End A: 1/0 ASCR, 2/0 Str., 1/0 Str. Compact, Red, End B: 2 ASCR, 1-2 Str., Red, Die: 840
HESCO Part Number
BLBIKL35
UPC
78378605021
Manufacturer Part Number
IKL35
Manufacturer
Thomas & Betts
$15.72Â /Â E
EACH
EACH
- Specifications
- Resources
Packaging
| Inner Quantity | :Â Â | 25 |
| Inner Dimensions (inches) | :Â Â | 7.4x6.9x4.8 |
| Outer Quantity | :Â Â | 100 |
| Outer Dimensions (inches) | :Â Â | 14.2x10.1x8.3 |
| Weight Uom | :Â Â | 22.69 lbs. per 100 |
North American Specifications (UNSPSC) | ||
| UNSPSC | :Â Â | 39121449 Wire or cable compression splice |
| IGCC | :Â Â | 4669 Wire or cable compression splice |
| Brand Name | :Â Â | Blackburn |
| Type | :Â Â | Service Entrance Splices |
| Special Features | :Â Â | Pre-insulated for fast, easy installation of large home or commercial service entrances. Concave polyethylene end caps seal out dirt, but are easily pierced when inserting conductor. |
| Application | :Â Â | For Combinations of Aluminum-to-Aluminum and Aluminum-to-Copper Conductors. Use as a low tension reducing sleeve for Insulated Conductor. |
| Standard | :Â Â | RUS Listed. Passes the Requirements of ANSI C119.4 |
| Size | :Â Â | 5-1/2 inch |
| Connection | :Â Â | Crimp/ Compression |
| Conductor Range | :Â Â | End A: 1/0 ASCR, 2/0 Stranded, 1/0 Stranded. Compact, End B: 2 ASCR, 1-2 Stranded. |
| Number Of Conductors | :Â Â | 2 |
| Material | :Â Â | Aluminum |
| Insulation | :Â Â | Yes |
| Mounting | :Â Â | None |
| Environmental Conditions | :Â Â | All Seasons / Conditions |
Packaging
Inner Quantity :Â Â 25 Inner Dimensions (inches) :Â Â 7.4x6.9x4.8 Outer Quantity :Â Â 100 Outer Dimensions (inches) :Â Â 14.2x10.1x8.3 Weight Uom :Â Â 22.69 lbs. per 100 North American Specifications (UNSPSC)
UNSPSC :Â Â 39121449 Wire or cable compression splice IGCC :Â Â 4669 Wire or cable compression splice Brand Name :Â Â Blackburn Type :Â Â Service Entrance Splices Special Features :Â Â Pre-insulated for fast, easy installation of large home or commercial service entrances. Concave polyethylene end caps seal out dirt, but are easily pierced when inserting conductor. Application :Â Â For Combinations of Aluminum-to-Aluminum and Aluminum-to-Copper Conductors. Use as a low tension reducing sleeve for Insulated Conductor. Standard :Â Â RUS Listed. Passes the Requirements of ANSI C119.4 Size :Â Â 5-1/2 inch Connection :Â Â Crimp/ Compression Conductor Range :Â Â End A: 1/0 ASCR, 2/0 Stranded, 1/0 Stranded. Compact, End B: 2 ASCR, 1-2 Stranded. Number Of Conductors :Â Â 2 Material :Â Â Aluminum Insulation :Â Â Yes Mounting :Â Â None Environmental Conditions :Â Â All Seasons / Conditions - Downloads
Spec SheetTechnical Drawing / Spec Sheet CanadaSafety Data Sheet (SDS) Global
