N12 JIC Continuous Hinge Quick Release 6X6X4 Carbon Steel - Gray
MFG #B060604CHQR
$124.92Â /Â E
EACH
EACH
Product Description:
N12 JIC Continuous Hinge Quick Release 6X6X4 Carbon Steel - Gray
HESCO Part Number
WIEB060604CHQR
UPC
786725331703
Manufacturer Part Number
B060604CHQR
Manufacturer
Wiegmann
N12 JIC Continuous Hinge Quick Release 6X6X4 Carbon Steel - Gray
MFG #B060604CHQR
Product Description:
N12 JIC Continuous Hinge Quick Release 6X6X4 Carbon Steel - Gray
HESCO Part Number
WIEB060604CHQR
UPC
786725331703
Manufacturer Part Number
B060604CHQR
Manufacturer
Wiegmann
$124.92Â /Â E
EACH
EACH
- Features
- Specifications
- Resources
- Bodies fabricated from 14 gauge and doors fabricated from 16 gauge steel. Continuously welded seams ground smooth, less knockouts or holes. Lids are sealed with closed cell oil resistant neoprene gasket. External mounting plates, top and bottom of enclosure. Weldnuts are provided for mounting optional panels securely. External quick release latches secure cover. Standard continuous hinged secures cover. Grounding provisions provided.
Specifications
| Buy American Compliant | :Â Â | Contact Manufacturer |
| Country of Origin | :Â Â | MX |
| Each - Width | :Â Â | 9.250 in |
| Application | :Â Â | Intended for use as electrical junction boxes, terminal wiring boxes, and instrument housings. Hinged door with quick-release latching provide convenient access. Designed to provide protection from dust, dirt, oil, and water. |
| Color | :Â Â | Ansi-61 Gray Textured |
| Cover Type | :Â Â | Hinged Cover |
| Cubic Capacity | :Â Â | 144 cu.in |
| Depth | :Â Â | 4 in |
| Height | :Â Â | 6 in |
| Mounting | :Â Â | External Mounting Plates |
| NEMA Rating | :Â Â | 12 |
| Standard | :Â Â | cULus |
| Type | :Â Â | Enclosure |
| Width | :Â Â | 6 in |
| Weight | :Â Â | 4.2 lb. |
| Mounting Type | :Â Â | External Mounting Plates |
| Nema Rating | :Â Â | 12 |
| ARRA Compliant | :Â Â | Contact Manufacturer |
| Class Code | :Â Â | P04 |
| Description - Invoice | :Â Â | JIC-CHINGE-QR-6X6X4 |
| Freight Class Code | :Â Â | 06316009 |
| Harmonization Code | :Â Â | 7326908688 |
| Image Actual Or Representative | :Â Â | R |
| Lead Time | :Â Â | 21 wk |
| MSDS Flag | :Â Â | No |
| Order Multiple | :Â Â | 1 EA |
| Returnable Indicator | :Â Â | No |
| Stock Indicator | :Â Â | S - Shelf Stock |
| Sub Class Code | :Â Â | P04P067 |
| Latches Type | :Â Â | Quick-Release Latches |
| UL Listed | :Â Â | Yes |
| Construction | :Â Â | Continuously Welded Seams |
| Material | :Â Â | Carbon Steel |
| Base Unit of Measure | :Â Â | EA |
| BOX SIZE | :Â Â | 4.900x10.800x9.250 (in) |
| Carton - Gross Weight per Pack | :Â Â | 4.200 lb. |
| Carton - Number of Sub Packs | :Â Â | 1 |
| Carton - Pack Description | :Â Â | Carton |
| Carton - SCC-14 Next Lower Level Sub Pack | :Â Â | 00786725331703 |
| Carton - Total Units | :Â Â | 1 EA |
| Pallet Height | :Â Â | 38.800 in |
| Pallet Length | :Â Â | 48.000 in |
| Pallet Weight | :Â Â | 554.600 lb. |
| Pallet Width | :Â Â | 40.000 in |
Certifications | ||
| Certified Listed | :Â Â | cULus |
| EU RoHS Indicator | :Â Â | Yes |
| Listings | :Â Â | UL, CSA |
- Bodies fabricated from 14 gauge and doors fabricated from 16 gauge steel. Continuously welded seams ground smooth, less knockouts or holes. Lids are sealed with closed cell oil resistant neoprene gasket. External mounting plates, top and bottom of enclosure. Weldnuts are provided for mounting optional panels securely. External quick release latches secure cover. Standard continuous hinged secures cover. Grounding provisions provided.
Specifications
Buy American Compliant :Â Â Contact Manufacturer Country of Origin :Â Â MX Each - Width :Â Â 9.250 in Application :Â Â Intended for use as electrical junction boxes, terminal wiring boxes, and instrument housings. Hinged door with quick-release latching provide convenient access. Designed to provide protection from dust, dirt, oil, and water. Color :Â Â Ansi-61 Gray Textured Cover Type :Â Â Hinged Cover Cubic Capacity :Â Â 144 cu.in Depth :Â Â 4 in Height :Â Â 6 in Mounting :Â Â External Mounting Plates NEMA Rating :Â Â 12 Standard :Â Â cULus Type :Â Â Enclosure Width :Â Â 6 in Weight :Â Â 4.2 lb. Mounting Type :Â Â External Mounting Plates Nema Rating :Â Â 12 ARRA Compliant :Â Â Contact Manufacturer Class Code :Â Â P04 Description - Invoice :Â Â JIC-CHINGE-QR-6X6X4 Freight Class Code :Â Â 06316009 Harmonization Code :Â Â 7326908688 Image Actual Or Representative :Â Â R Lead Time :Â Â 21 wk MSDS Flag :Â Â No Order Multiple :Â Â 1 EA Returnable Indicator :Â Â No Stock Indicator :Â Â S - Shelf Stock Sub Class Code :Â Â P04P067 Latches Type :Â Â Quick-Release Latches UL Listed :Â Â Yes Construction :Â Â Continuously Welded Seams Material :Â Â Carbon Steel Base Unit of Measure :Â Â EA BOX SIZE :Â Â 4.900x10.800x9.250 (in) Carton - Gross Weight per Pack :Â Â 4.200 lb. Carton - Number of Sub Packs :Â Â 1 Carton - Pack Description :Â Â Carton Carton - SCC-14 Next Lower Level Sub Pack :Â Â 00786725331703 Carton - Total Units :Â Â 1 EA Pallet Height :Â Â 38.800 in Pallet Length :Â Â 48.000 in Pallet Weight :Â Â 554.600 lb. Pallet Width :Â Â 40.000 in Certifications
Certified Listed :Â Â cULus EU RoHS Indicator :Â Â Yes Listings :Â Â UL, CSA - Downloads
Spec SheetMSDS
STEP 3D Model Asset ReferenceCatalog Full Asset ReferenceCustomer Notices Asset ReferenceSales Drawing Asset ReferenceTerms and Conditions Asset ReferenceHWDB060604CHQR-S.dxfB060604CHQR-MOD.dxfMOD Center Drawings Instructions
