N12 JIC Lift-Off Cover 12X10X5 Carbon Steel - Gray
MFG #B121005
$188.94Â /Â E
EACH
EACH
Product Description:
N12 JIC Lift-Off Cover 12X10X5 Carbon Steel - Gray
HESCO Part Number
WIEB121005
UPC
786725330805
Manufacturer Part Number
B121005
Manufacturer
Wiegmann
N12 JIC Lift-Off Cover 12X10X5 Carbon Steel - Gray
MFG #B121005
Product Description:
N12 JIC Lift-Off Cover 12X10X5 Carbon Steel - Gray
HESCO Part Number
WIEB121005
UPC
786725330805
Manufacturer Part Number
B121005
Manufacturer
Wiegmann
$188.94Â /Â E
EACH
EACH
- Features
- Specifications
- Resources
- Bodies fabricated from 14 gauge and doors fabricated from 16 gauge steel. Continuously welded seams ground smooth, less knockouts or holes. Lids are sealed with closed cell oil resistant neoprene gasket. External mounting plates, top and bottom of enclosure. Weldnuts are provided to secure optional back panel. External screw clamps are quick and easy to operate. Lift off cover design. Chain holds cover to box when cover is removed. Grounding provisions provided.
Specifications
| Buy American Compliant | :Â Â | Contact Manufacturer |
| Country of Origin | :Â Â | US |
| Each - Width | :Â Â | 11.000 in |
| Application | :Â Â | The Hubbell Wiegmann B Series JIC box is a standard of the automotive industry but has wide application in other industries. The box incorporates a chain secured lift off cover and is designed to safeguard components against exposure to dust, dirt, oil, a |
| Color | :Â Â | Ansi-61 Gray Textured |
| Cover Type | :Â Â | Lift Off |
| Cubic Capacity | :Â Â | 600 cu.in |
| Depth | :Â Â | 5 in |
| Height | :Â Â | 12 in |
| Mounting | :Â Â | External Mounting Plates |
| NEMA Rating | :Â Â | 12 |
| Standard | :Â Â | cULus |
| Type | :Â Â | Enclosure |
| Width | :Â Â | 10 in |
| Weight | :Â Â | 12 lb. |
| Mounting Type | :Â Â | External Mounting Plates |
| Nema Rating | :Â Â | 12 |
| ARRA Compliant | :Â Â | Contact Manufacturer |
| Class Code | :Â Â | P04 |
| Description - Invoice | :Â Â | JIC,CS,CLAMP COVER,12X10X5 |
| Freight Class Code | :Â Â | 06316009 |
| Harmonization Code | :Â Â | 7326908688 |
| Image Actual Or Representative | :Â Â | R |
| Lead Time | :Â Â | 21 wk |
| MSDS Flag | :Â Â | No |
| Order Multiple | :Â Â | 1 EA |
| Returnable Indicator | :Â Â | Yes |
| Stock Indicator | :Â Â | S - Shelf Stock |
| Sub Class Code | :Â Â | P04P067 |
| Latches Type | :Â Â | Clamps |
| UL Listed | :Â Â | Yes |
| Construction | :Â Â | Continuously Welded Seams |
| Material | :Â Â | Carbon Steel |
| Base Unit of Measure | :Â Â | EA |
| BOX SIZE | :Â Â | 6.500x14.000x11.000 (in) |
| Carton - Gross Weight per Pack | :Â Â | 12.000 lb. |
| Carton - Number of Sub Packs | :Â Â | 1 |
| Carton - Pack Description | :Â Â | Carton |
| Carton - SCC-14 Next Lower Level Sub Pack | :Â Â | 00786725330805 |
| Carton - Total Units | :Â Â | 1 EA |
| Pallet Height | :Â Â | 50.000 in |
| Pallet Length | :Â Â | 48.000 in |
| Pallet Weight | :Â Â | 637.200 lb. |
| Pallet Width | :Â Â | 40.000 in |
Certifications | ||
| Certified Listed | :Â Â | cULus |
| EU RoHS Indicator | :Â Â | Yes |
| Listings | :Â Â | UL, CSA |
- Bodies fabricated from 14 gauge and doors fabricated from 16 gauge steel. Continuously welded seams ground smooth, less knockouts or holes. Lids are sealed with closed cell oil resistant neoprene gasket. External mounting plates, top and bottom of enclosure. Weldnuts are provided to secure optional back panel. External screw clamps are quick and easy to operate. Lift off cover design. Chain holds cover to box when cover is removed. Grounding provisions provided.
