N4 Gasketed Screw-Cover 16X16X6 Carbon Steel - Galvanized
MFG #WA161606GSCG
$286.52Â /Â E
EACH
EACH
Product Description:
N4 Gasketed Screw-Cover 16X16X6 Carbon Steel - Galvanized
HESCO Part Number
WIEWA161606GSCG
UPC
786725848782
Manufacturer Part Number
WA161606GSCG
Manufacturer
Wiegmann
N4 Gasketed Screw-Cover 16X16X6 Carbon Steel - Galvanized
MFG #WA161606GSCG
Product Description:
N4 Gasketed Screw-Cover 16X16X6 Carbon Steel - Galvanized
HESCO Part Number
WIEWA161606GSCG
UPC
786725848782
Manufacturer Part Number
WA161606GSCG
Manufacturer
Wiegmann
$286.52Â /Â E
EACH
EACH
- Features
- Specifications
- Resources
- Bodies and covers fabricated from 14 gauge G-9- grade galvanized steel
- Seams are continuously welded and ground smooth
- Covers contain closed cell oil resistant neoprene gasket
- Enclosure comes with stainless steel cover screws which thread into seals wells to prevent liquid, dust, etc. from entering into the box through the screw holes
- Ground stud located in door
- No holes, knockout, or rear mounting holes
Certifications
| Certified Listed | :Â Â | cULus |
| EU RoHS Indicator | :Â Â | No |
| Listings | :Â Â | UL |
Specifications | ||
| Actual Depth | :Â Â | 11.25 in |
| Actual Height | :Â Â | 11.250 in |
| Actual Width | :Â Â | 12.060 in |
| Buy American Compliant | :Â Â | Contact Manufacturer |
| Country of Origin | :Â Â | US |
| Each - Width | :Â Â | 12.060 in |
| Application | :Â Â | Designed for use as wiring box, junction box, pull box, and terminal box in many indoor or outdoor applications where dust or moisture is a problem. |
| Cover Type | :Â Â | Screw Cover |
| Cubic Capacity | :Â Â | 1452 cu.in |
| Depth | :Â Â | 11 in |
| Height | :Â Â | 11 in |
| NEMA Rating | :Â Â | 4 |
| Standard | :Â Â | cULus |
| Type | :Â Â | Enclosure |
| Width | :Â Â | 12 in |
| Weight | :Â Â | 23 lb. |
| Nema Rating | :Â Â | 4 |
| ARRA Compliant | :Â Â | Contact Manufacturer |
| Class Code | :Â Â | P01 |
| Description - Invoice | :Â Â | SC,BOX,GASKETED,GALV,16X16X6 |
| Freight Class Code | :Â Â | 06316009 |
| Harmonization Code | :Â Â | 7326908688 |
| Image Actual Or Representative | :Â Â | R |
| Lead Time | :Â Â | 21 wk |
| MSDS Flag | :Â Â | No |
| Order Multiple | :Â Â | 1 EA |
| Returnable Indicator | :Â Â | Yes |
| Stock Indicator | :Â Â | S - Shelf Stock |
| Sub Class Code | :Â Â | P01P006 |
| UL Listed | :Â Â | Yes |
| Construction | :Â Â | Continuously Welded Seams |
| Material | :Â Â | Carbon Steel |
| Base Unit of Measure | :Â Â | EA |
| BOX SIZE | :Â Â | 11.250x18.500x12.060 (in) |
| Carton - Gross Weight per Pack | :Â Â | 23.000 lb. |
| Carton - Number of Sub Packs | :Â Â | 1 |
| Carton - Pack Description | :Â Â | Carton |
| Carton - SCC-14 Next Lower Level Sub Pack | :Â Â | 00786725848782 |
| Carton - Total Units | :Â Â | 1 EA |
| Pallet Weight | :Â Â | 0.000 lb. |
- Bodies and covers fabricated from 14 gauge G-9- grade galvanized steel
- Seams are continuously welded and ground smooth
- Covers contain closed cell oil resistant neoprene gasket
- Enclosure comes with stainless steel cover screws which thread into seals wells to prevent liquid, dust, etc. from entering into the box through the screw holes
- Ground stud located in door
- No holes, knockout, or rear mounting holes
Certifications
Certified Listed :Â Â cULus EU RoHS Indicator :Â Â No Listings :Â Â UL Specifications
Actual Depth :Â Â 11.25 in Actual Height :Â Â 11.250 in Actual Width :Â Â 12.060 in Buy American Compliant :Â Â Contact Manufacturer Country of Origin :Â Â US Each - Width :Â Â 12.060 in Application :Â Â Designed for use as wiring box, junction box, pull box, and terminal box in many indoor or outdoor applications where dust or moisture is a problem. Cover Type :Â Â Screw Cover Cubic Capacity :Â Â 1452 cu.in Depth :Â Â 11 in Height :Â Â 11 in NEMA Rating :Â Â 4 Standard :Â Â cULus Type :Â Â Enclosure Width :Â Â 12 in Weight :Â Â 23 lb. Nema Rating :Â Â 4 ARRA Compliant :Â Â Contact Manufacturer Class Code :Â Â P01 Description - Invoice :Â Â SC,BOX,GASKETED,GALV,16X16X6 Freight Class Code :Â Â 06316009 Harmonization Code :Â Â 7326908688 Image Actual Or Representative :Â Â R Lead Time :Â Â 21 wk MSDS Flag :Â Â No Order Multiple :Â Â 1 EA Returnable Indicator :Â Â Yes Stock Indicator :Â Â S - Shelf Stock Sub Class Code :Â Â P01P006 UL Listed :Â Â Yes Construction :Â Â Continuously Welded Seams Material :Â Â Carbon Steel Base Unit of Measure :Â Â EA BOX SIZE :Â Â 11.250x18.500x12.060 (in) Carton - Gross Weight per Pack :Â Â 23.000 lb. Carton - Number of Sub Packs :Â Â 1 Carton - Pack Description :Â Â Carton Carton - SCC-14 Next Lower Level Sub Pack :Â Â 00786725848782 Carton - Total Units :Â Â 1 EA Pallet Weight :Â Â 0.000 lb. - Downloads
