N12 Double Door Console Body 50X48X23 Carbon Steel - Gray
MFG #WC1448BD
$8,082.80Â /Â E
EACH
EACH
Product Description:
N12 Double Door Console Body 50X48X23 Carbon Steel - Gray
HESCO Part Number
WIEWC1448BD
UPC
786725444304
Manufacturer Part Number
WC1448BD
Manufacturer
Wiegmann
N12 Double Door Console Body 50X48X23 Carbon Steel - Gray
MFG #WC1448BD
Product Description:
N12 Double Door Console Body 50X48X23 Carbon Steel - Gray
HESCO Part Number
WIEWC1448BD
UPC
786725444304
Manufacturer Part Number
WC1448BD
Manufacturer
Wiegmann
$8,082.80Â /Â E
EACH
EACH
- Features
- Specifications
- Resources
- Designed to hold electrical and electronic controls and instruments
- Pushbuttons, pilot lights, meters, switches etc., can be mounted on the instrument panel
- Interior components are motorized on stationary sub panels, swing-out sub panels or relay rack angles (panels are optional)
- Heavy duty construction provides protection from dirt, dust, oil and water
- Numerous accessories and variable combinations make these consoles most versatile.
Specifications
| Actual Depth | :Â Â | 23.13 in |
| Actual Height | :Â Â | 50.130 in |
| Actual Width | :Â Â | 48.13 in |
| Buy American Compliant | :Â Â | Contact Manufacturer |
| Country of Origin | :Â Â | US |
| Each - Width | :Â Â | 50.000 in |
| Number of Doors (Fixed) | :Â Â | 2 |
| Application | :Â Â | Designed to hold electrical and electronic controls and instruments. Pushbuttons, pilot lights, meters, switches, etc., can be mounted on the instrument panel. Interior components are motorized on stationary sub panels, swing-out sub panels, or relay rack |
| Color | :Â Â | Ansi-61 Gray Textured |
| Cubic Capacity | :Â Â | 55200 cu.in |
| Depth | :Â Â | 23 in |
| Height | :Â Â | 50 in |
| NEMA Rating | :Â Â | 12 |
| Standard | :Â Â | cULus |
| Type | :Â Â | Console Body |
| Width | :Â Â | 48 in |
| Weight | :Â Â | 290 lb. |
| Nema Rating | :Â Â | 12 |
| ARRA Compliant | :Â Â | Contact Manufacturer |
| Class Code | :Â Â | P02 |
| Description - Invoice | :Â Â | CONSOLE,OT,CS,BODY,50"X48"X23" |
| Freight Class Code | :Â Â | 06111001 |
| Harmonization Code | :Â Â | 7326908688 |
| Image Actual Or Representative | :Â Â | R |
| Lead Time | :Â Â | 21 wk |
| MSDS Flag | :Â Â | No |
| Order Multiple | :Â Â | 1 EA |
| Returnable Indicator | :Â Â | Yes |
| Stock Indicator | :Â Â | S - Shelf Stock |
| Sub Class Code | :Â Â | P02P036 |
| Latches Type | :Â Â | 3-Point Keylocking Handle |
| UL Listed | :Â Â | Yes |
| Material | :Â Â | Carbon Steel |
| Base Unit of Measure | :Â Â | EA |
| BOX SIZE | :Â Â | 50.130x23.130x48.130 (in) |
| Carton - Gross Weight per Pack | :Â Â | 290.000 lb. |
| Carton - Number of Sub Packs | :Â Â | 1 |
| Carton - Pack Description | :Â Â | Carton |
| Carton - SCC-14 Next Lower Level Sub Pack | :Â Â | 00786725444304 |
| Carton - Total Units | :Â Â | 1 |
Certifications | ||
| Certified Listed | :Â Â | cULus |
| EU RoHS Indicator | :Â Â | Yes |
| Listings | :Â Â | UL, CSA |
- Designed to hold electrical and electronic controls and instruments
- Pushbuttons, pilot lights, meters, switches etc., can be mounted on the instrument panel
- Interior components are motorized on stationary sub panels, swing-out sub panels or relay rack angles (panels are optional)
- Heavy duty construction provides protection from dirt, dust, oil and water
- Numerous accessories and variable combinations make these consoles most versatile.
Specifications
Actual Depth :Â Â 23.13 in Actual Height :Â Â 50.130 in Actual Width :Â Â 48.13 in Buy American Compliant :Â Â Contact Manufacturer Country of Origin :Â Â US Each - Width :Â Â 50.000 in Number of Doors (Fixed) :Â Â 2 Application :Â Â Designed to hold electrical and electronic controls and instruments. Pushbuttons, pilot lights, meters, switches, etc., can be mounted on the instrument panel. Interior components are motorized on stationary sub panels, swing-out sub panels, or relay rack Color :Â Â Ansi-61 Gray Textured Cubic Capacity :Â Â 55200 cu.in Depth :Â Â 23 in Height :Â Â 50 in NEMA Rating :Â Â 12 Standard :Â Â cULus Type :Â Â Console Body Width :Â Â 48 in Weight :Â Â 290 lb. Nema Rating :Â Â 12 ARRA Compliant :Â Â Contact Manufacturer Class Code :Â Â P02 Description - Invoice :Â Â CONSOLE,OT,CS,BODY,50"X48"X23" Freight Class Code :Â Â 06111001 Harmonization Code :Â Â 7326908688 Image Actual Or Representative :Â Â R Lead Time :Â Â 21 wk MSDS Flag :Â Â No Order Multiple :Â Â 1 EA Returnable Indicator :Â Â Yes Stock Indicator :Â Â S - Shelf Stock Sub Class Code :Â Â P02P036 Latches Type :Â Â 3-Point Keylocking Handle UL Listed :Â Â Yes Material :Â Â Carbon Steel Base Unit of Measure :Â Â EA BOX SIZE :Â Â 50.130x23.130x48.130 (in) Carton - Gross Weight per Pack :Â Â 290.000 lb. Carton - Number of Sub Packs :Â Â 1 Carton - Pack Description :Â Â Carton Carton - SCC-14 Next Lower Level Sub Pack :Â Â 00786725444304 Carton - Total Units :Â Â 1 Certifications
Certified Listed :Â Â cULus EU RoHS Indicator :Â Â Yes Listings :Â Â UL, CSA - Downloads
Spec SheetMSDS
STEP 3D Model Asset ReferenceCatalog Full Asset ReferenceCustomer Notices Asset ReferenceSales Drawing Asset ReferenceTerms and Conditions Asset ReferenceHWDWC1448BD-S.dxf
